English−100
PROTECT
PROTECT MENU
POWER SAVE SETTINGS
POWER SAVE Enables or disables the monitor entering power saving mode. When [ENABLE] is selected, the monitor
goes into power saving mode after the period of time has passed with no input signal detected or signal
loss has occurred. When the monitor is in power saving mode, the LED power indicator will change color.
Refer to the Power indicator table (see page 73). When [DISABLE] is selected, the monitor doesn’t go
into power saving mode.
Please refer to the monitor’s specifications (see “P435” on page 76, “P495” on page 77, “P555”
on page 78, “MA431” on page 79, “MA491” on page 80 and “MA551” on page 81) for power
consumption information.
NOTE: • When the monitor is connected to a computer, the computer’s display adapter may not stop
sending digital data even though there is no image on-screen. If this occurs the monitor will not
switch into standby mode.
• If [AUTO OFF] or [CUSTOM] is selected in [HUMAN SENSING]*
1
, the power save function
does not work.
*
1
: This function is available only when connecting the optional sensor unit.
TIME SETTING Sets the amount of time the monitor should wait for input signal before going into power save mode.
POWER SAVE MESSAGE Shows a message as the monitor is entering low power mode.
QUICK START When [ENABLE] is selected, the monitor will quickly return to the [ON] state when a signal is detected.
Enabling this option increases standby power consumption.
THERMAL MANAGEMENT
FAN CONTROL When [AUTO] is selected, the fans will only turn on when the internal temperature reaches the temperature
set at any one of the sensors in this menu. The fans will automatically turn off when the monitor is cooler.
When [ON] is selected the fans are always on. The fans cannot be turned off manually.
Use the + and – button on the remote control to adjust the maximum internal temperature the monitor can
reach before the fan turns on when [AUTO] is selected.
FAN SPEED The [FAN SPEED] can be adjusted between LOW and HIGH.
DISPLAY Shows the status of the internal temperature of the monitor.
FAN STATUS Shows the status of the monitor’s internal fan.
INTERNAL
TEMPERATURE
Shows the internal temperature of the monitor.
SLOT Shows the internal temperature of the Option Board.
FAN STATUS Shows the status of the fan for the Option Board.
INTERNAL
TEMPERATURE
Shows the internal temperature of the Option Board.
SYSTEM FAN
REQUIREMENT
Show the requirement operation from the Option Board.
OPTION
COMPUTE MODULE
