NEC MultiSync P435 User Manual

English−80
MA491
Product Specifications
LCD Module
Pixel Pitch:
Resolution:
Color:
Brightness:
Contrast Ratio:
Viewing Angle:
49”/123.2 cm diagonal
0.280 mm
3840 x 2160
Over 1073 million colors (depending on display card used)
500 cd/m
2
(Max.) @25 °C
1100:1
89° (typ) @ CR>10
Frequency Horizontal:
Vertical:
15 - 136 kHz (HDMI)/22 - 134 kHz (DisplayPort)
23 - 76 Hz
Pixel Clock 25 - 600 MHz (HDMI)
25 - 1040 MHz (DisplayPort1)
25 - 570 MHz (DisplayPort2)
Color Gamut 86 % (DCI-P3)
Viewable Size 1073.80 x 604.00 mm
Input/Output Signal
DisplayPort DisplayPort Connector Digital RGB DisplayPort (Up to 7680 x 4320 (30 Hz)*
1
, HDCP 1.3/2.2)
HDMI HDMI Connector Digital YUV
Digital RGB
HDMI (Up to 4096 x 2160 (60 Hz)*
1
, HDCP 1.4/2.2)
Audio terminal
AUDIO Input DisplayPort Connector Digital Audio PCM 32, 44.1, 48 kHz (16/20/24 bit)
HDMI Connector Digital Audio PCM 32, 44.1, 48 kHz (16/20/24 bit)
AUDIO
Output
Stereo Mini Jack Analog Audio Stereo L/R 0.5 Vrms
HDMI Connector (ARC*
2
) Digital Audio PCM 32, 44.1, 48 kHz (16/20/24 bit)
Speaker Output External Speaker Jack 15 W + 15 W (8 ohm)
Control RS-232C In:
LAN:
Remote IN:
9 Pin D-sub
RJ-45 10 BASE-T/100 BASE-TX x 2
Stereo Mini Jack 3.5 mm Ø
USB USB-A USB 2.0 Downstream port
USB-B USB 2.0 Downstream port
SERVICE Power supply port, 5 V/2 A (max.)
Firmware update port
Power Supply 2.7 - 1.1 A @ AC 100 - 240 V 50/60 Hz
Power Consumption Normal operation: Approx. 85 W
Operational Environment Temperature*
3
:
Humidity:
Altitude:
0 - 40 °C / 32 - 104 °F
20 - 80 % (without condensation)
0 - 3000 m (Brightness may decrease with altitude)
Storage Environment Temperature:
Humidity:
–20 - 60 °C / –4 - 140 °F
10 - 90 % (without condensation) / 90 % - 3.5 % x (Temp - 40 °C) regarding over 40 °C
Dimension*
4
1103.4 (W) x 636.2 (H) x 71.9 (D) mm/43.44 (W) x 25.04 (H) x 2.83 (D) inches (with handle)
1103.4 (W) x 636.2 (H) x 61.1 (D) mm/43.44 (W) x 25.04 (H) x 2.41 (D) inches (without handle)
Weight 22.9 kg (50.5 lbs)
VESA-compatible mounting interface 300 mm x 300 mm (M6, 4 Holes)
Power Management VESA DPM
Power supply for Option Board 12 V/5.5 A
Power supply for Raspberry Pi Compute Module 12 V/1.67 A
NOTE: Technical specifications are subject to change without notice.
*
1
: Compressed image.
*
2
: HDMI IN1 only.
*
3
: When you use Option Board accessories, please contact your supplier for detailed information.
*
4
: Measurements are of the monitor only and do not include removable parts that protrude.
