NEC MultiSync UN552V User Manual

English−28
Media Player
The internal Media Player will play audio and video files that are stored on a microSD memory card or USB storage device.
See page 39 for instructions on using the Media Player.
Connect Compatible microSD Memory Card
Format a microSD memory card in the FAT32 format or FAT16 format. Refer to the computer’s instruction manual or help file on
how to format a microSD memory card.
NOTE:  Up to 32GB microSDHC is supported.
The monitor is not guaranteed to work with all microSD memory cards sold commercially.
microSD with CPRM is not supported.
microSD UHS-1 or UHS-2 are not supported.
• When inserting a microSD memory card, please make sure of the microSD memory card is in the correct direction then
insert it. Fully insert the microSD memory card and press in until the spring lock is engaged.
• When ejecting a microSD memory card from the microSD card slot, press the center of the microSD memory card to release
the spring lock, then take it out.
Installing microSD card slot cover
To secure your microSD memory card, we recommend you to install the microSD card slot cover.
Please insert the edge of the microSD card cover into the hole. Secure it in place with the provided screw.
(Recommended Fasten Force: 139 - 189 N•cm).
microSD card cover is installed.Hole

NEC MultiSync UN552V Specifications

General

Pixel pitch	0.63 x 0.63 mm
Response time	8 ms
Display diagonal	55 \
Display brightness	500 cd/m²
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	23 - 86 Hz
Horizontal scan range	26 - 134 kHz
Contrast ratio (typical)	1700:1
Display diagonal (metric)	138.78 cm
Active display area (W x H)	1209.63 x 680.34 mm
Operating hours (hours/days)	24/7
Maximum refresh rate	60 Hz
Annual energy consumption	328 kWh
Purpose	Universal
Orientation	Horizontal/Vertical
Product color	Black
Product design	Video wall
Placement supported	Indoor
Bezel width (bottom)	0.44 mm
Panel mounting interface	400 x 400 mm
USB ports quantity	5
DisplayPorts quantity	3
Compatible memory cards	MicroSD (TransFlash)
Ethernet LAN data rates	10, 100 Mbit/s
VGA (D-Sub) input ports	1
HDMI input ports quantity	2
Audio formats supported	AAC, MP3, WAV
Image formats supported	JPG, PNG
Video formats supported	FLV, H.264, MOV, MP4, MPG, WMV
Power consumption (standby)	0.5 W
Power consumption (typical)	225 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Certification	BSMI; CE; EAC; EMC B; FCC; PSB; RCM; REACH; RoHS; SASO; TÜV GS; TÜV S; UL/C-UL; VCCI
Sustainability certificates	RoHS
Cables included	AC, DisplayPort, HDMI
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	98.6 mm
Width	1210.5 mm
Height	681.2 mm
Weight	25800 g
