English−78
Supporting HDMI CEC Command
Please connect a CEC supporting device to HDMI2 port.
OSD menu HDMI CEC command name Explanation Setting
CEC
(Consumer
Electronics
Control)
One Touch Play When a CEC supported HDMI device is turned
on, the monitor connected to the device by an
HDMI cable also automatically turns on. After
the monitor powers on, [INPUT] automatically
switches to the [HDMI2].
If the monitor is turned on when HDMI CEC
devices are turned on, it changes the [INPUT]
from the current one to [HDMI2].
NETWORK INFORMATION
LAN
CHANGE PASSWORD
SECURITY
IR LOCK SETTINGS
KEY LOCK SETTINGS
DDC/CI
PING
IP ADDRESS RESET
AUTO DIMMING
POWER INDICATOR
NETWORK FUNCTIONS
USB
CEC
CEC
ON / OFF
AUTO TURN OFF
YES / NO
AUDIO RECEIVER
YES / NO
SEARCH DEVICE
YES / NO
To set the CEC options, please follow the steps
below.
Press the Menu button to open the OSD.
Using the + - buttons, navigate to
[CONTROL] to [CEC], then press SET/POINT
ZOOM button to enter the CEC options.
Use the + - buttons to highlight [ON], then press
SET/POINT ZOOM button to enable CEC.
Remote Control Pass Through The monitor’s optional wireless remote control
button operation can function with HDMI CEC
supporting devices.
For example, if turning on the monitor by
wireless remote control and pressing the play
button, a HDMI CEC supporting device can also
be turned on and play.
Power Status Connected HDMI CEC supporting devices
obtain the monitor’s power status, such as if the
monitor is in standby mode or on.
System Information This function obtains the information for a
connected HDMI CEC supported device (CEC
version, Physical Address). In addition, this
function copes with the “Change Language
function”.
If the language for the monitor is changed, the
language for a connected HDMI CEC supported
device is changed to the same language, which
is selected for the monitor.
For the “Change Language function”, it is
necessary that the connected HDMI CEC
supported device be able to cope with multi-
language.
AUTO
TURN OFF
System Standby If the monitor is set to standby using the optional
wireless remote control, HDMI CEC supported
devices also go into standby at the same time.
If the monitor goes into standby while an HDMI
CEC supported device is recording, the device
remains on. Please refer to the user’s manual
supplied with the HDMI CEC supported device
for further information.
Use the buttons to select [AUTO TURN
OFF].
Use the + - buttons to highlight [YES], then press
the SET/POINT ZOOM button to select [YES].
AUDIO
RECEIVER
System Audio Control Please set an HDMI CEC audio amplifier
between the monitor and an HDMI CEC
supported device with an HDMI cable.
The Volume button on the optional wireless
remote control can control the volume of the
connected HDMI CEC audio amplifier.
While this function is active, the external speaker
connected to the monitor is set to MUTE
automatically.
Use the buttons to select [AUDIO
RECEIVER] then press SET/POINT ZOOM.
Use the + - buttons to highlight [YES], then press
the SET/POINT ZOOM button to select [YES].
SEARCH
DEVICE
Device OSD Name Transfer Use the + - buttons to highlight YES, then press
the SET/POINT ZOOM button to start the
search.
Use the buttons to select [SEARCH
DEVICE].
This function searches for CEC supported
devices on the monitor’s HDMI connections.
If a CEC device is successfully detected, this
function obtains the device’s name. The device’s
name and the HDMI connection it is found on
are displayed.
Routing Control By selecting a device name, the HDMI CEC
supported device input switches to the input you
selected. After selecting the device, wireless
remote control operation functions for the
selected device.
This CEC function is supporting Feature Abort.
Please refer to Connections (see
page 23) for HDMI CEC devices connection.
