English−38
Below is a brief summary of where controls are under each menu item. A table listing all options is located in “OSD Controls List”
on page 100.
INPUT: Select the input signal source.
PICTURE: Select one of the default picture modes, manually adjust the color settings, enable or disable
SpectraView Engine, and adjust the aspect ratio, image flip, and rotation.
AUDIO: Adjust volume, balance, equalizer, input source, and multi-picture mode output.
SCHEDULE: Create auto power on/off schedules, set holidays and week day/weekend schedules, set the date and
time, daylight savings time, and auto-off.
MULTI-INPUT: Select Picture-In-Picture and Picture-By-Picture settings, signal input detection, and connection
terminal settings.
OSD: Select options related to the on-screen display menu, such as language, the amount of time the OSD stays
on-screen, the location of the menu, transparency, rotation, etc.
MULTI-DISPLAY: Set the monitor’s monitor ID, configure settings for multi-monitor setup.
PROTECT: Select options related to protecting the monitor hardware, such as configuring the cooling fans, adjusting
automatic power save and power on delay, enabling the screen saver and alert mail to be notified when an error
occurs in the monitor.
CONTROL: Set network information, security, power, etc.
OPTION: Select settings related to an Option Board if installed.
SYSTEM: View the monitor information (model, serial number, carbon footprint), firmware version, mac address, or
perform a factory reset.
COMPUTE MODULE: This menu is only available when the optional Raspberry Pi Compute Module Interface Board
and Raspberry Pi Compute Module are installed. See page 98.
