NEC MultiSync V552 User Manual

English-8
Parts Name and Functions
Control Panel
쐃 POWER button
Switches the power on/off. See also page 17.
쐇 MUTE button
Switches the audio mute ON/OFF.
쐋 INPUT button
Acts as SET button within OSD menu. (Toggle switches
between [DVI], [DPORT], [VGA], [RGB/HV], [HDMI], [DVD/
HD], [SCART], [VIDEO1], [VIDEO2] or [S-VIDEO]). These are
available input only, shown as their factory preset name.
쐏 PLUS button
Acts as (+) button to increase the adjustment with OSD menu.
Increases the audio output level when the OSD menu is
turned off.
쐄 MINUS button
Acts as (-) button to decrease the adjustment with OSD menu.
Decreases the audio output level when the OSD menu is
turned off.
쐂 UP button
Activates the OSD menu when the OSD menu is turned-off.
Acts as
button to move the highlighted area up to select
adjustment items within OSD menu.
쐆 DOWN button
Activates the OSD menu when the OSD menu is turned-off.
Acts as
button to move the highlighted area down to select
adjustment items within OSD menu.
쐊 EXIT button
Activates the OSD menu when the OSD menu is turned-off.
Acts as EXIT button within the OSD to move to previous
menu.
쐎 Remote control sensor and Power Indicator
Receives the signal from the remote control (when using the
wireless remote control). See also page 12.
Glows green when the LCD monitor is in active mode*.
Glows red when the LCD is in POWER OFF mode.
Glows amber when the monitor is in Power Save Mode.
Green and Amber blink alternately while in Power Standby
mode with the “SCHEDULE SETTINGS” function enabled.
When a component failure is detected within the monitor, the
indicator will blink red.
* If “OFF” is selected in “POWER INDICATOR” (see page 25),
LED will not light when the LCD monitor is in active mode.
쐅 AMBIENT LIGHT SENSOR
Detects the level of ambient light, allowing the monitor
to make automatic adjustments to the backlight setting,
resulting in a more comfortable viewing experience. Do not
cover this sensor. See page 19.
Control Key Lock Mode
This control completely locks out access to all Control Key
functions. To activate the control key lock function, press
both
and and hold down simultaneously for more than
3 seconds. To resume user mode, press both and and
hold simultaneously for more than 3 seconds.

NEC MultiSync V552 Specifications

General

Panel life	- h
Pixel pitch	0.63 x 0.63 mm
Response time	8 ms
Display diagonal	55 \
Display brightness	430 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	50 - 85 Hz
Horizontal scan range	31.5 - 91.1 kHz
LED backlighting type	Edge-Lit LED
Supported video modes	1080p
Touchscreen technology	Infrared
Display number of colors	16.78 million colors
Active display area (W x H)	1209.6 x 680.4 mm
Orientation	Horizontal/Vertical
Product color	Black
Product design	Digital signage flat panel
Bezel width (top)	41.4 mm
Panel mounting interface	300 x 300 mm
Wi-Fi	-
DVI-D ports quantity	2
Cable lock slot type	Kensington
Power consumption (standby)	2 W
Power consumption (typical)	100 W
Package depth	250 mm
Package width	1430 mm
Package height	920 mm
Operating altitude	0 - 3000 m
Non-operating altitude	3000 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
RMS rated power	10 W
Cables included	AC, DVI

Weight and Dimensions

Depth	86.5 mm
Width	1294.4 mm
Height	765.2 mm
Weight	40800 g
