English-17

English

Connecting a Personal Computer

Connecting your computer to your LCD monitor will enable you to reproduce your computer’s video signal output.

Some display cards may not be able to support the required resolution for proper image reproduction.

Your LCD monitor shows proper image by adjusting the factory preset timing signal automatically.

Resolution

Scanning frequency

VGA DVI

HDMI DisplayPort

Remarks

Horizontal Vertical MODE1 MODE2 1.1a 1.2

640 x 480 31.5 kHz 60 Hz Yes Yes Yes Yes Yes Yes

800 x 600 37.9 kHz 60 Hz Yes Yes Yes Yes Yes Yes

1024 x 768 48.4 kHz 60 Hz Yes Yes Yes Yes Yes Yes

1280 x 720 45.0 kHz 60 Hz Yes Yes Yes Yes Yes Yes

1280 x 768 47.8 kHz 60 Hz Yes Yes Yes Yes Yes Yes

1280 x 800 49.7 kHz 60 Hz Yes Yes Yes Yes Yes Yes

1280 x 960 60.0 kHz 60 Hz Yes Yes No No No No

1280 x 1024 64 kHz 60 Hz Yes Yes Yes Yes Yes Yes

1360 x 768 47.7 kHz 60 Hz Yes Yes Yes Yes Yes Yes

1366 x 768 47.7 kHz 60 Hz Yes Yes Yes Yes Yes Yes

1400 x 1050 65.3 kHz 60 Hz Yes Yes Yes Yes Yes Yes

1440 x 900 55.9 kHz 60 Hz Yes Yes Yes Yes Yes Yes

1600 x 1200 75.0 kHz 60 Hz Yes Yes Yes Yes Yes Yes Compressed image

1680 x 1050 65.3 kHz 60 Hz Yes Yes Yes Yes Yes Yes

1920 x 1080 67.5 kHz 60 Hz Yes Yes Yes Yes Yes Yes Recommended resolution

1920 x 1200 74.6 kHz 60 Hz Yes No Yes Yes Yes Yes Compressed image

1920 x 2160 133.3 kHz 60 Hz No No Yes Yes Yes Yes Compressed image

3840 x 2160 65.7 kHz 30 Hz No No No No Yes Yes Compressed image

3840 x 2160 67.5 kHz 30 Hz No No Yes Yes No No Compressed image

3840 x 2160 133.3 kHz 60 Hz No No No Yes No Yes* Compressed image

3840 x 2160 135.0 kHz 60 Hz No No No Yes No Yes* Compressed image

4096 x 2160 54.0 kHz 24 Hz No No Yes Yes No No Compressed image

*: Only HBR2 is set.

•฀Input฀TMDS฀signals฀conforming฀to฀DVI฀standards.

•฀To฀maintain฀the image reproduction quality, use a cable that conforms to DVI standards.

Connecting a Player or Computer with HDMI

•฀฀Please฀use฀a฀HDMI฀cable฀with฀the฀HDMI฀logo.

•฀฀It฀may฀take฀a฀moment฀for฀the฀signal฀to฀appear.

•฀฀Some฀display฀cards฀or฀drivers฀may฀not฀display฀an฀image฀correctly.

•฀฀When฀you฀use฀a฀computer฀with฀HDMI,฀please฀set฀OVER฀SCAN฀to฀“AUTO”฀or฀“OFF”฀(see฀page฀34).

•฀฀Please check display card when image is compressed with 1920 x 1080.

•฀฀To output HDMI audio, set [HDMI1] or [HDMI2] at AUDIO INPUT in the OSD or choose [HDMI1] or [HDMI2] by the remote

control AUDIO INPUT button.

•฀฀If the input resolution is 3840 x 2160 (60 Hz), please set MODE2 at HDMI in TERMINAL SETTINGS (See page 37).

•฀฀If the monitor’s main power is turned on after a connected computer is turned on, sometimes images are not displayed.

In this case, please turn off the computer then turn it on again.

Connecting a Computer with DisplayPort

•฀Please฀use฀a฀DisplayPort฀cable฀with฀the฀DisplayPort฀compliance฀logo.

•฀To use the DisplayPort out connector, please refer to Video out (See page 61).

•฀It฀may฀take฀a฀moment฀for฀the฀signal฀to฀appear.

•฀When฀connecting฀a฀DisplayPort฀cable฀to฀a฀component฀with฀a฀signal฀conversion฀adapter,฀an฀image฀may฀not฀appear.

•฀Select฀DisplayPort฀cables฀feature฀a฀locking฀function.฀When฀removing฀this฀cable,฀hold฀down฀the฀top฀button฀to฀release฀the฀lock.

•฀To output DisplayPort audio, set [DisplayPort1] or [DisplayPort2] at AUDIO INPUT in the OSD or choose [DisplayPort1] or

[DisplayPort2] by the remote control AUDIO INPUT button.

•฀To display individual images at each connected monitors with the DisplayPort out connector, please set DisplayPort1.2 and

MST at DisplayPort in the TERMINAL SETTINGS (See page 37).

•฀If the monitor’s main power is turned on after a connected computer is turned on, sometimes images are not displayed.

In this case, please turn off the computer then turn it on again.
