English-28

Picture Mode

Depending on the setting of SPECTRAVIEW ENGINE in the OSD PICTURE (see page 34), the selection choices for the Picture

Mode are different.

SPECTRAVIEW ENGINE is set to “ON”:

Select from ﬁve different picture modes, either via the OSD menu item PICTURE MODE, or using the PICTURE MODE button

on the wireless remote control.

Select the Picture Mode with the wireless remote control

By pressing the Picture Mode button, the picture mode changes.

SVE-1

SVE-2 SVE-3 SVE-4 SVE-5

Select or change the Picture Mode in the OSD menu item PICTURE MODE

Select a setting from SVE-1 SETTING to SVE-5 SETTING at PICTURE MODE.

Select a preset item at PRESET.

Choose the Picture Mode that is most suitable for the type of content that is shown.

•฀Several modes are selectable (sRGB, Adobe

RGB SIM., eciRGB_v2 SIM., DCI SIM., REC-Bt709, HIGH BRIGHT, FULL,

DICOM SIM, PROGRAMMABLE).

•฀Each฀PICTURE฀MODE฀includes฀LUMINANCE,฀WHITE,฀GAMMA,฀BLACK,฀RED,฀GREEN,฀BLUE,฀COLOR฀VISION฀EMU,฀

UNIFORMITY and METAMERISM settings.

PRESET Types

PRESET PURPOSE

sRGB

The standard color space used for the Internet, Windows

operating systems and digital cameras.

Recommended setting for general color management.

Adobe

RGB SIM.

Provides a standard color space used in high-end graphics applications such as professional digital still cameras and

imaging.

eciRGB_v2 SIM.

Provides a color space proﬁle recommended by ECI (The European Color Initiative).

DCI SIM.

Color setting for digital cinema.

REC-Bt709

Color setting for High-deﬁnition television.

HIGH BRIGHT

Highest brightness setting.

FULL

Native LCD panel color gamut. Suitable for use with color managed applications.

DICOM SIM.

Setting that conforms to the DICOM standard for the Grayscale Standard Display Function.

PROGRAMMABLE

For the Hardware Calibration by NEC Display Solutions GammaCompMD QA software (some OSD settings are

disabled).

MODE PURPOSE

LUMINANCE Adjusts the overall image and screen background brightness.

Press “LEFT” or “RIGHT” to adjust.

WHITE Adjusts the white color by temperature or x, y setting. A lower color temperature will result in a reddish screen and a

higher color temperature in a bluish screen. A larger x value will result in a reddish screen, a larger y value changes

the screen to greenish, and smaller x,y values will change the screen to bluish white.
