English-44
SLOT2 CH SELECT This function is available only when SLOT2 CH SETTING is 1CH.
DisplayPort Shows the DisplayPort signal from a slot 2 type PC option on the full screen.
TMDS Shows the TMDS signal from a slot 2 type PC option on the full screen.
RESET Resets the AUDIO setting back to the factory setting within the OPTION menu.
SYSTEM
MONITOR INFORMATION Shows the model name, serial number and firmware version of your monitor.
CARBON SAVINGS: Display the estimated carbon saving information in kg-CO2. The carbon footprint factor in
the carbon saving calculation is based on the OECD (2008 Edition).
CARBON USAGE: Display the estimated carbon usage information in kg-CO2. This is the arithmetic estimation,
not actual measurement value. This estimation is based without any options.
FIRMWARE Displays firmware version that is installed to the monitor.
MAC ADDRESS Displays the MAC ADDRESS.
FACTORY RESET All items are returned to factory shipment state.
NOTE: You can reset all items in all daisy chained monitors. Please be careful to avoid resetting all items
inadvertently.
COMPUTE MODULE
COMPUTE MODULE When a Raspberry Pi Compute Module Interface Board and Raspberry Pi Compute Module are installed,
additional OSD menu items will be available for configuring the related settings. Please do not change settings in
COMPUTE MODULE yourself.
POWER
POWER SUPPLY Controls power to the Compute Module.
AUTO POWER ON When set to Enable, power to the Compute Module will be turned on automatically when the display power is
turned on.
SERVICE MENU
SETTING LOCK Locks all settings under COMPUTE MODULE.
USB BOOT MODE When set to Enable, the Compute Module will appear as a USB device to a PC connected to the USB2 input on
the display and can be programmed with an Operating System. When set to Disable, the Compute Module will
boot normally.
IR SIGNAL Enables or disables the forwarding of IR remote control signals.
MONITOR CONTROL Enables or disables the internal serial connection between the display and Compute Module.
SHUTDOWN SIGNAL Enables or disables the use of GPIO 23 to signal that power to the compute module will be shutting down.
POWER SUPPLY
OFF DELAY
This sets the time delay after the Shutdown Signal is set until the power to the Compute Module is turned off.
Configure this to allow adequate time for any software to shutdown safely.
WDT Enables or Disables the display's built in Watchdog Timer function for the Compute Module.
START UP TIME This sets the time delay for when the display should start receiving WDT reset commands.
PERIOD TIME This sets the maximum amount of time within which the display must receive WDT reset commands from the
Compute Module.
CHANGE PASSWORD
Default values can be provided on request.
