Specifications - P554
Product Specifications
LCD Module
Pixel Pitch:
Resolution:
Color:
Brightness:
Contrast Ratio:
Viewing Angle:
55"/138.78 cm diagonal
0.630 mm
1920 x 1080
Over 1073 million colors (depending on display card used)
700 cd/m
2
฀(Max.)฀@25°C
1200:1
89°฀(typ)฀@฀CR>10
Frequency Horizontal:
Vertical:
15.625/15.734 kHz, 31.5 kHz - 91.1 kHz
50.0 - 85.0 Hz (Analog Input)
24.0 - 85.0 Hz (Digital Input)
Pixel Clock Analog: 13.5 MHz, 25.0 MHz - 195.0 MHz
Digital: 25.0 MHz - 165.0 MHz (DVI), 25.0 MHz - 600.0 MHz (HDMI/DisplayPort)
Viewable Size 1209.6 x 680.4 mm
Input Signal
DVI DVI-D 24pin Digital RGB DVI (HDCP1.4)
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
1
, 1920X1080 (60Hz), 1080p, 1080i
DisplayPort DisplayPort Connector Digital RGB DisplayPort V1.2 (HDCP1.3)
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
1
, WUXGA60*
1
, 1920x1080 (60 Hz),
1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 3840x2160 (24Hz/30Hz/60Hz
(DisplayPort1.2))*
1,
*
3
VGA
(RGB)*
4
15pin Mini D-sub Analog RGB 0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
1
, WUXGA60*
1
, 1920X1080 (60Hz)
Sync Separate: TTL level (Pos./Neg.)
Composite sync on Green Video: 0.3 Vp-p Neg.
HDMI HDMI Connector Digital YUV
Digital RGB
HDMI (HDCP1.4/2.2)
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
1
, WUXGA60*
1
, 1920x1080 (60 Hz),
1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz,
3840x2160 (30Hz/24Hz/25Hz/60Hz (MODE2))*
1,
*
3
, 4096x2160 (24Hz)*
1,
*
3
VGA
(YPbPr)*
4
15pin Mini D-sub Component Y: 1.0 Vp-p/75ohm, Cb/Cr (Pb/Pr): 0.7 Vp-p/75 ohm
HDTV/DVD: 1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz
VIDEO*
4
RCA port Composite 1.0 Vp-p/75 ohm
NTSC/PAL/SECAM/4.43NTSC/PAL60
Output Signal
DisplayPort DisplayPort Connector Digital RGB DisplayPort V1.2 (HDCP1.3)
AUDIO
AUDIO
Input
Stereo Mini Jack Analog Audio Stereo L/R 0.5 Vrms
HDMI Connector Digital Audio PCM 32, 44.1, 48 KHz (16/20/24bit)
DisplayPort Connector Digital Audio PCM 32, 44.1, 48 KHz (16/20/24bit)
AUDIO
Output
Stereo Mini Jack Analog Audio Stereo L/R 0.5 Vrms
Speaker Output External Speaker Jack 15 W + 15 W (8 ohm)
Internal Speaker 10 W + 10 W (Stereo)
Control RS-232C In:
LAN:
Remote IN:
9 Pin D-sub
RJ-45 10 BASE-T/100 BASE-TX x 2
Stereo Mini Jack 3.5 mm Ø
SD card Hub Port: microSD card. Up to 32GB microSDHC is supported.
USB Hub USB1:
USB2:
USB CM1 (2A):
USB CM2:
USB MP:
USB 2.0 Downstream port
USB 2.0 Upstream port
Power supply port, 5V/2A (max.)
USB service port for maintenance
Media Player/Firmware update port
Power Supply 3.6 - 1.5 A @ 100-240V AC, 50/60Hz
Power Consumption Normal operation: Approx. 125 W
Operational Environment Temperature*
2
:
Humidity:
Altitude:
0฀-฀40°C฀/฀32฀-฀104°F,฀0฀-฀35°C฀/฀32฀-฀95°F฀(Slot฀2฀type฀PC฀with฀Face฀up฀position฀or฀with฀Face฀
down position)
20 - 80% (without condensation)
0 - 3000 m (Brightness may decrease with altitude)
Storage Environment Temperature:
Humidity:
-20฀-฀60°C฀/฀-4฀-฀140°F
10฀-฀90%฀(without฀condensation)฀/฀90%฀-฀3.5%฀x฀(Temp฀-฀40°C)฀regarding฀over฀40°C
Dimension*
5
1244 (W) x 714.8 (H) x 62.9 (D) mm/49 (W) x 28.1 (H) x 2.5 (D) inches
Weight 24.6 kg (54.2 lbs)
VESA compatible mounting interface 300 mm x 300 mm (M6, 4 Holes)
Power Management VESA DPM
Power supply for Slot 2 type OPTION 16V/3.6 A
NOTE: Technical specifications are subject to change without notice.
*
1
: Compressed image.
*
2
: When you use option board accessories, please contact your supplier for detailed information.
*
3
: Reproduced text may look blurred.
*
4
: Common terminal.
*
5
: Measurements are of the monitor only and do not include removable parts that protrude.

NEC MultiSync V554 Specifications

General

Power consumption (standby)	- W
Power consumption (typical)	120 W
Portrait mode	Yes
Annual energy consumption	175 kWh
Panel life	- h
Pixel pitch	- mm
Response time	8 ms
Display diagonal	55 \
Display brightness	500 cd/m²
Display technology	LED
Vertical scan range	24 - 85 Hz
Horizontal scan range	31.5 - 91.1 kHz
LED backlighting type	Edge-LED
Display number of colors	1.073 billion colors
Display diagonal (metric)	138.78 cm
Active display area (W x H)	1209.6 x 680.4 mm
Internal memory	1 GB
Processor cores	4
Processor model	A53
Processor family	ARM Cortex
Processor frequency	1.2 GHz
Audio formats supported	MP3, WAV
Image formats supported	JPG, PNG
Video formats supported	FLV, MOV, MP4
Internal storage capacity	16 GB
USB version	2.0
USB ports quantity	5
DisplayPorts quantity	3
Ethernet LAN data rates	10, 100 Mbit/s
VGA (D-Sub) input ports	1
Purpose	-
Operating hours (hours/days)	24/7
Product color	Black
Product design	Digital signage flat panel
Bezel width (bottom)	14.2 mm
Panel mounting interface	300 x 300 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	C-tick; CE; EMC Class B; FCC; PSB; TÜV GS; UL/C-UL or CSA; VCCI
Sustainability certificates	RoHS, ENERGY STAR
RMS rated power	20 W
Cables included	AC, DVI

Weight and Dimensions

Depth	62.9 mm
Width	1244 mm
Height	714.8 mm
Weight	24500 g
