View devices currently on the mesh network
You can view all satellites and devices that are currently connected to your mesh network.
To view devices on the mesh network:
1.
Launch a web browser from a computer or mobile device that is connected to your
mesh network.
2.
Enter http://www.routerlogin.net.
A login window opens.
3. Enter the router admin user name and password.
The user name is admin. The password is the one that you specified the first time
that you logged in. The user name and password are case-sensitive.
The BASIC Home page displays.
4. Select Attached Devices.
The Attached Devices page displays.
The Connected Satellite table displays the following information:
•
Device Name: The satellite model, device name, and IP address.
•
IP Address: The satellite IP address. This IP address can change because the
router assigns an IP address to each satellite when it joins the network.
•
Connection Type: The satellite is connected to the mesh network through a WiFi
or wired Ethernet connection.
•
Connected Mesh Device: The router or (other) satellite that the satellite is
connected to. The Orbi router’s or satellite’s MAC address also displays.
•
Backhaul Status: The quality of the backhaul status between the satellite and
the router or (other) satellite.
The Connected Devices table displays the following information:
•
Status: Displays only if network access control (see Network access control list
on page 42) is enabled. The field displays if a device is allowed or blocked.
•
Connection Type: The device is connected to the mesh network through a WiFi
or wired Ethernet connection.
•
Device Name: The device model, device name, and IP address.
User Manual103Manage your Router and
Satellite
Nighthawk Tri-band Mesh WiFi 6
