2. SPECIFICATIONS
2-6
Marks * show dry weight.
2.4 TRANSPORTATION
2.4.1 OVERALL DIMENSIONS OF MACHINE ON A TRAILER
(1) 5.62m (18ft-5in) Boom+2.87m (9ft-5in) Arm+0.80m
3
(1.05cu•yd) Bucket
4. Lubricant and water (Assembly of following :) 490 (1,080) ←
4.1 Hydraulic oil 200 (440) ←
4.2 Engine oil 20 (44) ←
4.3 Fuel 250 (550) ←
4.4 Water 20 (44) ←
Shoe type
600mm (23.6in) 600mm (23.6in) LC
Item
Width mm (ft-in) 2,800 (9'2") 2,990 (9'10")
Weight kg (lbs) 22,300kg (49,200 lbs) 22,700kg (50,100 lbs)
Unit ; kg (lb)
Model
E225BSR E225BSRLC
Item
8320 (27'4")
270
(10.6")
3610 (11'10")
3130 (10'3")
600
(23.6")
3730 (12'3")
3130 (10'3")
150
(5.9")
To Next Page
