2. SPECIFICATIONS
2-11
2.8 COMBINATIONS OF ATTACHMENT
Standard combination
General operation : Excavation or loading of sand, gravel, and clay
Light operation : Mainly loading or loose gravel (e.g., cultivation or loading of sand or gravel)
Prohibited combination : There are problems from the view points of strength and stability.
• Use the attachments recommended by manufacturer.
The trouble due to the use in the condition "Use not allowed" described in the above table is not included in our
responsibility
Do not turn the bucket back to front to use as a shovel.
If the bucket other than backhoe bucket is used in reversed position, it causes damage of arm and bucket.
Bucket Available Arm
Type
Heaped capacity
m
3
(cu•yd)
Struck
m
3
(cu•yd)
2.87m (9ft-5in) Arm
(STD)
2.87m (9ft-5in)+1.52m (5ft)
Extension Arm
Hoe bucket
0.51 (0.67) 0.39 (0.51)
0.70 (0.92) 0.52 (0.68)
STD
0.80 (1.05)
0.59 (0.77)
0.93 (1.2) 0.67 (0.88)
Breaker — —
Nibbler — —
To Next Page
