2. SPECIFICATIONS
2-12
2.9 ENGINE SPECIFICATIONS
2.9.1 SPECIFICATIONS
Applicable machine E225BSR, E225BSRLC
Engine model HINO J05E-TA
Type
Water-cooled, 4 cycle 4 cylinder direct injection type
diesel engine with inter cooler turbo-charger
Number of cylinder×Bore×Stroke mm (in) 4 × 112 × 130 (4.41 × 5.12)
Total displacement cc (cu•in) 5,123 (313)
Compression ratio 18.0
Rated output kW (PS) at min
-1
114 (155) at 2,000
Maximum torque
N•m (lb•ft) at
min
-1
572 (422) at 1,600
High idling min
-1
2,000 ± 30
Low idling min
-1
1,000 ± 30
Injection starting pressure MPa (psi) 3.2 (464)
Thermostat action
Start/Full open
K (°F)
350 (170) / 363 (194)
Firing order 1 - 3 - 4 - 2
Compression pressure
MPa (psi)
at min
-1
3.4~3.7 (493~537) at 280
Fuel injection timing Degree (°) BTDC 0°
Valve clearance
Valve clearance Open Close
Intake valve 0.3 mm at cool
14°before top
dead center
30°after bottom
dead center
Exhaust valve 0.45 mm at cool
54°before bottom
dead center
13°after top dead
center
Starter capacity V × kW 24 × 5.0
Generator capacity (Alternator) V × A 24 × 50
Cooling fan drive method
ø650 (25.6") × suction type 7 fans, V-belt drive,
pulley ratio Crank / Fan= 0.89
Engine oil quantity L (gal)
Full level 18.0 (4.76)
Low level 15.0 (3.96)
Total 20.5 (5.42)
Dry weight kg (lbs) 580 (1,280)
Fuel consumption ratio
(At rated output)
g/kW•h (g/ps•h) 217 (160)
Allowable inclination Degree (°) Front / Rear and Right / Left : 35°
Dimension (L×W×H) mm (in) 1,063 × 725 × 995 (3ft-5.86in × 28.5in × 39.2in)
Rotating direction Counterclockwise seeing from flywheel side
