New Holland E225BSR User Manual

3. ATTACHMENT DIMENSIONS
3-4
3.1.2 BOOM MAINTENANCE STANDARD
(1) Clearance of pin and bushing on boom section
Fig. 3-2 Clearance of pin and bushing on boom section
Unit : mm (in)
Symbol Item
Standard value Clearance
Remedy
Pin dia.
Pin dia.
tolerance
Bushing i.d.
tolerance
Standard
value
Repairable
level
Service
limit
A Boom foot
ø 90
(3.5433)
+ 0.020
(+0.0008)
- 0.020
(-0.0008)
+ 0.217
(+0.0085)
+ 0.071
(+0.0028)
+ 0.237
(+0.0093)
+ 0.051
(+0.0020)
More than
2.0
(0.08)
2.5
(0.1)
Replace
bushing or
pin
B
Boom cylinder
(Head side)
ø 85
(3.3465)
0
- 0.040
(-0.0016)
+ 0.250
(+0.010)
+ 0.050
(+0.0020)
+ 0.290
(+0.0114)
+ 0.050
(+0.0020)
C
Boom cylinder
(Rod side)
+ 0.020
(+0.0008)
- 0.020
(-0.0008)
+ 0.270
(+0.0106)
+ 0.030
(+0.0010)
D
Arm cylinder
(Head side)
ø 80
(3.1496)
+ 0.238
(+0.0090)
+ 0.079
(+0.0030)
+ 0.258
(+0.0100)
+ 0.059
(+0.0020)
D
C
B
A
