New Holland E225BSR User Manual

3. ATTACHMENT DIMENSIONS
3-12
3.3.4 BOSS SECTION DIMENSIONAL DRAWING
Fig. 3-9 Dimension of boss section
Unit : mm (ft-in)
Type of
bucket
Capacity of bucket
m
3
(cu•yd)
øA øB øC øD E F øG H I
Normal
digging
[STD]
0.80 (0.70)
114.3
(4.50")
84
(3.31")
105.5
(4.15")
111.5
(4.39")
23
(0.91")
38
(1.50")
17
(0.669")
13
(0.512")
2.5
(0.098")
0.51 (0.45)
0.70 (0.61)
0.93 (0.80)
1.05 (0.90)
Bucket capacity : SAE heaped (Struck)
A
E
H
5
(0.197")
15 (0.591")
F
o G
o A o B o C o D
DETAIL A
