Dimensions and setting-out coordinates
622
600
560 440
70
1800
650*
20-50
25
60
135
210
390
465
540
650*
* This dimension applies at 90° angle on the brine pipes (side connection). The dimension can vary approx. ±100 mm vertically as the brine
pipes consist in part of flexible pipes.
NIBE S1255Chapter 13 | Technical data68
13 Technical data
