CBOX1050
Installation and Programming Manual
1414
support.hysecurity.com
Below is a list of tools and materials necessary for installation of the control box:
• Wire cutters/strippers
• Basic hand tools (screwdrivers, wrenches, pliers, etc..)
• Drill and assorted size bits
• Hardware for mounting control box
• Electrical conduits, grommets, asphalt patch, etc. as needed
SECTION 5: INSTALLATION SAFETY
SECTION 6: TOOLS & MATERIALS NEEDED
The following are required to power the CBOX1050 control box:
• 12VDC battery to power the control board
• An AC-to-DC fully automatic charger, a 12-30 VDC power source, and/or solar panel to charge the battery.
Nice oers AC-to-DC converters and solar panel solutions for charging 12VDC batteries. Recommended battery
specifications are as follows:
6.1 CONTROL BOX POWER REQUIREMENTS
RECOMMENDED 12VDC BATTERY SPECIFICATIONS
12 Volt DC Output
Sealed lead acid starter battery
Terminal posts on top (not sides)
35 AMP hours or larger for AC charging applications
70 AMP hours or larger for Solar charging applications & Longer Backup
IMPORTANT!
’ The gate operator installation is NOT a “do-it-yourself” project. Contract a qualified gate operator
installation company to install this system to ensure a safe and reliable installation.
’ It is the responsibility of the property owner to ensure the installer is qualified to carry out the
installation in a safe and professional manner.
’ Consult local government agencies for up-to-date rules and regulations to satisfy licensing, codes
or regulations that regulate automated gate system design and installation.
’ The gate for which the gate operator is intended to be used should itself be installed correctly so
that it is level and plumb and the gate opens easily and evenly.
’ Note that Nice swing gate systems are not intended for installation on an incline.
CAUTION
’ Disconnect power at the control panel before making any electric service power connections.
’ Be aware of all moving parts and avoid close proximity to any pinch points.
NOTICE
Some purchased systems
may include a minimum
specified 12V battery as part
of the kit and a choice of solar
panel or AC battery charger.
