Technical Notes and Index
F6
Caring for the Camera
Cleaning
Do not use volatile organic solvents such as alcohol or thinner, chemical
detergents, anticorrosive agents, or anti-fogging agents.
Storage
Remove the battery if the camera will not be used for an extended period. Do not
store the camera with naphtha or camphor moth balls, or in any of the following
locations:
Next to equipment that produces strong electromagnetic fields, such as
televisions or radios
Exposed to temperatures below –10°C (14°F) or above 50°C (122°F)
Places that are poorly ventilated or subject to humidity of over 60%
To prevent mold or mildew, take the camera out of storage at least once a month.
Turn the camera on and release the shutter a few times before putting the camera
away again.
Be sure to read and follow the warnings given in “The Battery” (F3) of “Caring for
the Products” to store the battery.
Lens
Avoid touching glass parts with your fingers. Remove dust or lint with a blower
(typically a small device with a rubber bulb attached to one end that is
pumped to produce a stream of air out the other end). To remove fingerprints,
oily substances, or other stains that cannot be removed with a blower, carefully
wipe the lens with a dry soft cloth or eyewear cleaning cloth, using a spiral
motion that starts at the center of the lens and working toward the edges. Do
not wipe the lens forcibly or with a hard material. Failure to observe this
precaution could result in damage or trouble. If this fails, clean the lens using a
cloth lightly dampened with commercial lens cleaner.
Monitor
Remove dust or lint with a blower. To remove fingerprints, oily substances or
other stains, carefully wipe the monitor with a dry soft cloth or eyewear
cleaning cloth. Do not wipe the monitor forcibly or with a hard material. Failure
to observe this precaution could result in damage or trouble.
Body
Use a blower to remove dust, dirt, or sand, then wipe gently with a soft, dry
cloth. After using the camera at the beach or other sandy or dusty
environment, wipe off any sand, dust, or salt with a dry cloth lightly dampened
with fresh water and dry thoroughly. Note that foreign matter inside the
camera could cause damage not covered by the warranty.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Nikon COOLPIX P310 and is the answer not in the manual?

Nikon COOLPIX P310 Specifications

General IconGeneral
Megapixel1.61 MP
Camera typeCompact camera
Sensor typeCMOS
Image stabilizerYes
Total megapixels16.79 MP
Image sensor size1/2.3 \
Image formats supportedJPEG XR
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)-
Optical zoom4.2 x
Focal length range4.3 - 17.9 mm
Number of diaphragm blades6
Lens structure (elements/groups)7/6
Maximum focal length (35mm film equiv)100 mm
Minimum focal length (35mm film equiv)24 mm
FocusTTL
Focus adjustmentAuto/Manual
Auto focusing (AF) modesCentre weighted Auto Focus, Contrast Detection Auto Focus, Tracking Auto Focus
ISO sensitivity100, 400, 800, 1600, 3200, 6400
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)6400
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Camera shutter typeElectronic
Fastest camera shutter speed1/2000 s
Slowest camera shutter speed4 s
Flash range (tele)0.5 - 2.5 m
Flash range (wide)0.5 - 6.5 m
Power source typeBattery
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedH.264, MPEG4
Maximum video resolution1920 x 1080 pixels
Audio systemstereo
Memory slots1
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution (numeric)921000 pixels
USB version2.0
HDMI connector typeMini
Scene modesBacklight, Beach, Close-up (macro), Cuisine, Dawn, Dusk, Fireworks, Museum, Night portrait, Panorama, Party (indoor), Pet, Portrait, Snow, Sports, Sunset
Image editingCrop, Rotating
White balanceAuto, Cloudy, Daylight, Flash, Fluorescent, Incandescent, Manual
Self-timer delay2, 10 s
Languages supportARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Camera file systemDCF, DPOF, Exif 2.3
Battery life (CIPA standard)230 shots
Product colorBlack
Operating temperature (T-T)0 - 40 °C
Weight and Dimensions IconWeight and Dimensions
Depth32 mm
Width103 mm
Height58.3 mm
Weight194 g
