Nikon COOLPIX P310 User Manual

64
Features That Can Be Set Using the Multi Selector
Shooting Features
Smile Timer (Shooting Smiling Faces)
When this mode is selected, the camera detects smiling faces and automatically
releases the shutter even if you don’t press the shutter-release button.
• This function can be used when the shooting mode is A (auto), A, B, C, D, i,
scene mode Portrait or Night portrait.
1 Press J (n self-timer) on the multi selector.
• Change any flash mode, exposure, or shooting menu
settings before pressing the n button.
2 Use the multi selector to choose a (Smile
timer), and press the k button.
• If the k button is not pressed within a few seconds, the
selection will be canceled.
3 Frame the picture and wait for the subject to
smile without pressing the shutter-release
button.
• When the camera detects a face, a yellow double border
(focus area) is displayed around that face. When the
camera has focused on that face, the double border will
turn green for a moment and focus is locked.
• Up to three faces are detected. When more than one face is detected, the face closest
to the center of the frame is framed by a double border and the others by single
borders.
• If the camera detects that the face framed by the double border is smiling, the shutter
is automatically released.
• Each time the shutter is released, automatic shooting using face detection and smile
detection is repeated.
4 Finish shooting.
• To cancel smile detection and finish shooting, return to step 1 and select OFF.
Smile timer
1/250
1/250
1/250 F5.6
F5.6
F5.6
840
840
25m 0s
25m 0s
840
25m 0s

Nikon COOLPIX P310 Specifications

General

Megapixel	1.61 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	16.79 MP
Image sensor size	1/2.3 \
Image formats supported	JPEG XR
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	-
Optical zoom	4.2 x
Focal length range	4.3 - 17.9 mm
Number of diaphragm blades	6
Lens structure (elements/groups)	7/6
Maximum focal length (35mm film equiv)	100 mm
Minimum focal length (35mm film equiv)	24 mm
Focus	TTL
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Centre weighted Auto Focus, Contrast Detection Auto Focus, Tracking Auto Focus
ISO sensitivity	100, 400, 800, 1600, 3200, 6400
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	4 s
Flash range (tele)	0.5 - 2.5 m
Flash range (wide)	0.5 - 6.5 m
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	H.264, MPEG4
Maximum video resolution	1920 x 1080 pixels
Audio system	stereo
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	921000 pixels
USB version	2.0
HDMI connector type	Mini
Scene modes	Backlight, Beach, Close-up (macro), Cuisine, Dawn, Dusk, Fireworks, Museum, Night portrait, Panorama, Party (indoor), Pet, Portrait, Snow, Sports, Sunset
Image editing	Crop, Rotating
White balance	Auto, Cloudy, Daylight, Flash, Fluorescent, Incandescent, Manual
Self-timer delay	2, 10 s
Languages support	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Camera file system	DCF, DPOF, Exif 2.3
Battery life (CIPA standard)	230 shots
Product color	Black
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	32 mm
Width	103 mm
Height	58.3 mm
Weight	194 g
