63
Replacing Consumables
5
5
5.1
Replacing the lamp
• Be careful to avoid burns:
Wait until the lamp and nearby parts have cooled before attempting to replace
the lamp.
• Be careful to avoid electrical shock:
Turn off the power switch and unplug the power cord from the outlet.
• Be careful to avoid abnormal heat generation:
Use only the lamp specified.
• Be careful to avoid actions that might reduce lamp service life:
Avoid touching the bare lamp bulb with bare hands. Soiling will reduce the
service life of the lamp.
(1) Loosen the screw and lift the cover to
remove.
(2) Remove the old lamp.
(3) Replace with a new lamp.
Avoid touching the bare lamp bulb with bare
hands.
Use only the lamp specified. Refer to chapter
8 for the specified lamp.
(4) Replace the cover and fix it with the screw.
The lamphouse cover must be attached. Failure to replace the lamphouse cover
may result in burns or fire from the heat generated by the lamp.
Lamp
plug
Lam
To Next Page
