Nikon ECLIPSE 80i User Manual

68
Specifications
8
8.1
Specifications
Nikon Microscope ECLIPSE 80i
Model ECLIPSE 80i
Main unit
Optical system
Main unit
Illumination system
Focusing section
CFI60 system (infinity-corrected CF optical system)
T-shaped, double-winged
Flyeye illumination, power supply incorporated, with preset feature
12V/100W long-life halogen lamp
(specified lamp housing: D-CH precentered lamp housing)
(specified lamp: PHILIPS7724I or OSRAM HLX64623)
NCB11, ND8, ND32 incorporated (replaceable)
Manual single-axis coarse/fine motion handle system (right coarse/fine motion, left
coarse motion, calibration markings for fine motion: 1
µ
m/marking)
Stroke: 27 mm, with refocusing mechanism
Coarse motion handle: 14mm/revolution, fine motion handle: 0.1 mm/revolution
Tube section Binocular tube, ergonomic binocular tube (binocular section 100%, binocular: DSC
port = 50:50)
DSC port mountable to ergonomic binocular tube
Trinocular eyepiece tube FUW (binocular: straight = 100:0, 0:100)
Trinocular eyepiece tube TUW (binocular: straight = 100:0, 20:80, 0:100)
Nosepiece section Sextuple nosepiece, sextuple DIC nosepiece, intelligent septuple nosepiece,
intelligent septuple DIC nosepiece
Stage section Vertical stage (vertical stage R: main centering unit)
Condenser section Abbe condenser, achromat condenser, darkfield condenser (dry, oil)
Phase contrast condenser (cannot be attached to main centering unit), achromatic
aplanat condenser, LWD condenser
1-100X condenser, DIC condenser (oil), universal condenser (dry)
Eyepiece lens section 10x, field number: 22, 25
Input ratings
100-240V AC,
±
10%, 50/60Hz, 2.4A max.
AC adapter for C-BOX Manufacturer: ILAN ELECTRONICS LTD.
Model: F1650K
Rated input voltage: 100V-240V AC, 1.2A max., 50-60Hz
Rated input voltage: 12V DC, 3.5A max
Other: UL-listed, GS-approved, CE-certified
