Nikon ECLIPSE Si User Manual

Chapter 7 Specifications
119
7.2 Performance Properties
Model Name ECLIPSE Si RS Main Body
Optical System CFI60 (Infinity-corrected CF optical system)
Field Number: It depends on the combination.
When using Si eyepiece tubes and other optional products supporting a field
number of 20: FN 20
When using Ci eyepiece tubes and other optional products supporting a field
number of 22: FN 22
Eyepieces 10X, FN 20
Condenser Supports phase contrast microscopy, contains an aperture diaphragm, and comes
with a slot
Aperture diaphragm: Ø2 mm to Ø28 mm
Centering range: Ø4 mm or more
Vertical stroke: 2 mm upward and 13 mm downward
Attachment and removal mechanism: One-touch attachment and removal using
a leaf spring
Illumination device Koehler illumination device using a white LED, containing a fly-eye lens
Field diaphragm: Ø1.5 mm to Ø18 mm
Field lens: Allows two ø45-mm filters (of thickness 2.5 mm or
less) to be attached
Focusing Mechanism Manual single-axis coarse/fine movement handle (double-sided coarse/fine
movement)
Fine focus knob graduation: 2 μm/graduation
Fine focus knob travel: 0.2 mm/rotation
Coarse focus knob travel: 37.7 mm/rotation
Vertical movable range: 2 mm upward and 13 mm downward (from the focal
plane)
Stage Height of stage upper surface: 135 mm (above the table surface)
Stroke: Right and left axis: 76 mm
Front and back axis: 52 mm
0.1 mm graduation readable using Vernier
Specimen holder Supported slide glass thickness: 0.8 mm or more
Fastening method: One sided claw grip type
Allows up to two 76 mm x 26 mm glass slides to be attached
Revolving Nosepiece 5-hole fixed type, state-detecting type
Tilt angle: 22.5°
Objective attachment screw: M25
Supported microscopy
methods
Bright-field, phase-contrast, simple-polarizing, diascopic fluorescence, dark-field
