VBA23001-R.3762.A
- A45 ･ D90 -
ZERO/ABS
PRESET
TOL.
ON/OFF
0.00
mm
定盤
ZERO/ABS
PRESET
TOL.
ON/OFF
mm
定盤
1.82
"0" position of D90
・
"0" positioning of the dial gauge
Inspection and Adjustment of Body back
・
"0" positioning of the digital gauge
Surface plate
Surface plate
Surface plate
(1) Mount the tool (J18001-1) on the surface plate as above, then set the dial gauge to "0".
(2) From "0" position of (1), turn the index circle in the direction of the arrow so that the needle is on 18 (0.18mm)
position. (This position is "0" position of D90.)
(3) Measure the body back based on "0" position of the index circle.
1.82-1.82
＝
0
So this is within
standard.
e.g.
(1) Mount the tool (J18001-1) on the surface plate as above, then turn the digital gauge ON and press [ZERO/
ABS] button so that the value becomes "0".
(2) Measure the body back based on "0" position
(3) Subtract "1.82mm" from the measured value. If the value is "0±0.01 mm / Parallelism: 0.015mm or less",
it is within standard.
J18001-1
D90: 48.4948.49
㎜
- 46.67 46.67
㎜
(body back height)
＝
1.82
㎜
46.67
48.49
Difference from D90: 1.82
Turn counterclockwise by 0.18mm
Turn counterclockwise by 0.18mm
