VBA23001-R.3762 .A
- D34 ･ D90 -
・Take out the screw (#607), and remove the remote control unit (#B1056).Take out the screw (#607), and remove the remote control unit (#B1056).
・Unsolder at three places.Unsolder at three places.
Remote control unit (#B1056)
・Take out the three screws (#640).Take out the three screws (#640).
・Remove the M/D FPC unit (#B2455).Remove the M/D FPC unit (#B2455).
Screw (#640)
×
3
M/D FPC unit (#B2455)
Screw (#607)
Remote control unit
M/D FPC unit
INC
