version 1.0 / 19.10.1999 Page 12 of 41
Figure 4: current consumption values
Function mode Minimum current in mA Maximum current in mA
Off state 0 1,35
Sleep mode 1 5
Call mode GSM 900 250 440
Call mode GSM 1800 200 420
• Disconnect the PA's N501 / N501 lift L560 and check the current again
• Check if the current consumption comes from the first or second side of CCONT lift L103
• Check C105, C142 or N101
• Check soldering of the MAD
• Change MAD
• calibrate Battery value if charching stop to early or battery are to hot after charching (see also chapter "Not
charging)
Note! The Stand by time depends on the network side and of the user handling
Intermittent doesn't switch on
D210 FLASH faulty
• Check if the handset switch on after removing the battery for few seconds
or after connected it with the charger or headset
• D210 Flash internal fail
