Introduction
Phone description
MSM8960 is the main digital baseband ASIC in the phone. It contains functionality for LTE, WCDMA/HSPA+ and
GSM/GPRS/EDGE. The hardware accelerator is used for imaging and video.
PM8921 (N4200) is the main energy and power management controller for the phone.
Key components
Function Description Item ref
Main PWB 3VJ
Touch module A-cover touch assembly
Power management IC EM ASIC PM8921 N4200
RF ASIC RTR8600 N7650
Processor MSM8960 D4800
GSM/WCDMA B1/WCDMA
B5/LTE B1 PA
N7550
WCDMA B2 PA N7500
LTE B3 PA N7530
LTE B7 PA N7540
WCDMA B8/LTE B8 PA N7520
LTE B20 PA N7510
PA DC/DC converter FAN5903 N7525
SP12T antenna switch
module
LMSP3WQP-D51 N7505
SP5T div antenna switch SKY13358-388LF Z7590
DP4T switch SKY13421 N7575
Oscillators Crystal 19.2 MHZ
Crystal 27 MHZ
Crystal 48 MHZ
B4281
B4800
B6300
CMT memory POP 1 GB LPDDR2 (stacked with MSM8960) D4810
WLAN/Bluetooth/FM radio WCN3660 N6301
GPS GPS/Glonass integrated into RTR8600 N7650
GPS LNA (external) BGM1033N7 N7800
NFC PN544C3 N6500
Main RF connector X7812
RF connector For Band 7 antenna (RM-825) X7802
Diversity RF connector X7806
WLAN/BT RF connector X6300
RM-824; RM-825; RM-826
System Module
Issue 2 NOKIA INTERNAL USE ONLY Page 6 – 5
Copyright © 2012 Nokia. All rights reserved.
