SX-4T Smart card
SX-4T is a security device used to protect critical features in tuning and
testing as well as SIM lock opening.
XRS-6 RF cable 0730231
The RF cable is used to connect, for example, a module repair jig to
the RF measurement equipment.
SMA to N-Connector approximately 610 mm.
Attenuation for:
•
GSM850/900: 0.3+-0.1 dB
•
GSM1800/1900: 0.5+-0.1 dB
•
WCDMA V/VIII: 0.3+-0.1dB
•
WCDMA I/II: 0.5+-0.1dB
•
LTE B1/B3: 0.5+-0.1dB
•
LTE B7: 0.6+-0.1dB
•
LTE B8/20: 0.3+-0.1dB
•
BT/WLAN: 0.5+-0.1dB
Service concepts
POS (Point of Sale) flash concept
Figure 2 POS flash concept
RM-824; RM-825; RM-826
Service Tools and Service Concepts
Issue 2 NOKIA INTERNAL USE ONLY Page 2 – 9
Copyright © 2012 Nokia. All rights reserved.
