AFP-200 Instruction PN 15511:F2 10/11/99 45
2.7.6 Optional Modules
The AFP-200 control panel has an option module slot, using locations J6, J7, and J8 on the circuit board. There
are two optional modules available for the control panel, the 4XTM Transmitter Module and the RTM-8 Relay
Module. Jumper JP5 must be cut before installation of an optional module to enable module supervision.
Figure 2-32 Optional Module Location
J6
J7
J8
Jumper JP5
