System Bring-Up
For bring-up of a switch system with NVIDIA Onyx (MLNX-OS) operating system installed,
seeConfiguring Network Attributes Using NVIDIA Onyx (MLNX-OS).
For bring-up of a switch system with Cumulus Linux operating system installed, seeConfiguring
Network Attributes Using Cumulus Linux.
Configuring Network Attributes Using NVIDIA Onyx (MLNX-OS)
The procedures described in this chapter assume that you have already installed and powered on
the system according to the instructions in this document. The system comes with a pre-configured
DHCP. If you wish to disable it, refer to Disable Dynamic Host Configuration Protocol (DHCP). In case
a manual configuration is required, please refer to the instructions in Manual Host Configuration.
Manual Host Configuration
To perform initial configuration of the system:
Step 1. Connect a host PC to the Console RJ45 ( )port of the system, using the supplied
harness cable (DB9 to RJ45). Make sure to connect to the Console RJ45 port and not to the
(Ethernet) MGT ( ) port.
Step 2. Configure a serial terminal program (for example, HyperTerminal, minicom, or Tera Term) on
your host PC with the settings described in the table below. Once you perform that, you should get
the CLI prompt of the system.
Serial Terminal Program Configuration
Parameter
Setting
Baud Rate 115200
Data bits 8
Stop bits 1
•
•
•
Risk of electric shock and energy hazard. The two power supply units are
independent. Disconnect all power supplies to ensure a powered down state inside of
the switch platform.
ACHTUNG Gafahr des elektrischen Schocks. Entferrnen des Netzsteckers elnes
Netzteils spannungsfrei. Um alle Einhieten spannungsfrei zu machen sind die
Netzstecker aller Netzteile zu entfernen.
ATTENTION Risque de choc et de danger e’lectriques. Le de’branchment d’une seule
alimentation stabilise’e ne de’branch uniquement qu’un module “Alimentation
Stabilise’e”. Pour isoler completement le module en cause, Il faut de’brancher
toutes les alimentations stabilise’es.
