Appendixes
The document contains the following appendixes:
Accessory and Replacement Parts
Thermal Threshold Definitions
Interface Specifications
Disassembly and Disposal
Accessory and Replacement Parts
Ordering Part Numbers for Replacement Parts
Part Type Part
Number
Legacy
Part
Number
Description Supported
Systems
Rack
Installation
Kits
930-9NRKT-00
JN-000
MTEF-KIT-J Static rack installation kit for 1U\2U
systems into 4-poles, 430-800mm depth
racks
SN4600/SN4600C,
SN4410, SN4700
Fan Modules 930-9NFAN-00I
T-000
MTEF-FANF-
I
NVIDIA fan module, 80 x 80 [mm], P2C
Airflow, For SN4600 switch
SN4600
930-9NFAN-00
J7-000
MTEF-FANR-I NVIDIA fan module, 80 x 80 [mm], C2P
Airflow, For SN4600 switch
SN4600
930-9BFAN-00I
X-000
MTEF-FANF-
M
NVIDIA fan module, 40 x 40 [mm], P2C
Airflow For SN4700 switches
SN4700/SN4410
930-9BFAN-00J
B-000
MTEF-FANR-
M
NVIDIA fan module, 40 x 40 [mm], C2P
Airflow For SN4700 switches
SN4700/SN4410
930-9NFAN-00I
S-000
MTEF-FANF-
G
2U Systems Fan Module P2C Air flow with
Shutters
SN4600C
930-9NFAN-00
J6-000
MTEF-FANR-
G
2U Systems Fan Module C2P Air flow with
Shutters
SN4600C
Power
Supplies
930-9BPSU-00
JZ-000
MTEF-PSF-
AC- C
200G 1U systems 1100W AC Power Supply
w/ P2C airflow
SN4600C
930-9BPSU-00
JG-000
MTEF-PSR-
AC- C
200G 1U systems 1100W AC Power Supply
w/ C2P airflow
SN4600C
930-9NPSU-00
J2-000
MTEF-PSF-
AC-F
1500W AC Power Supply, P2C Air flow SN4600, SN4410,
SN4700
930-9NPSU-00
JJ-000
MTEF-PSR-
AC-F
1500W AC Power Supply, C2P Air flow SN4600, SN4410,
SN4700
Cables and
Harnesses
HAR000631 N/A RS232 Cable - DB9 to RJ45 2M harness 2M
for SX67X0 and SB78X0
SN4410, SN4600/
SN4600C, SN4700
