ML390/391 Turbo Printer Handbook 21
Switching Paper Paths
To switch from continuous-form feed from the rear or bottom (optional push or pull
tractor installed) of the printer to single-sheet feed from the top:
1. Tear off printed pages.
2. Press PARK button.
3. Swing wire guide up into paper separator, then pivot separator to upright posi-
tion.
4. Move paper lever to position marked “TOP”.
5. Load single sheet paper into paper separator.
To switch from top feed to continuous-form tear or bottom (optional push or pull
tractor installed) feed:
1. Make sure no sheet is in paper path (press FF/LOAD to remove single sheet from
path).
2. Lower paper separator to continuous forms position and swing wire guide over
onto pull-up roller assembly.
3. Move paper lever to position marked “REAR” or “BOT”, as appropriate.
4. Press FF/LOAD button. Continuous-form paper will advance into print position.
