Oki Data CONFIDENTIAL
44871001TH Rev.6
8-36
8. TROUBLESHOOTING PROCEDURES
8.5.3 Fax Error List
Termination Code List
# Value
(Hex)
Description
1. 0 NORMAL (Ended normally)
2. 1 STOP (A user cancelled a job during sending.)
3. 2 An incoming call was received. The produdre ended unsuccessfully (T1 timeout).
4. 3 CANCEL for shutdown
5. 11 Document jam during real time sending
6. 14 Memory Full during RX / Memory Full (Insufficient avaialble memory at the time
of receiving. Or exceeded a maximum number of received pages.)
7. 19 FAX ERROR_TX_JOB_DELETED (Cancellation of jobs waiting for sending:
Redialing, calling again & resending, and programed sending, including delayed
transmission)
8. 21 CONNECTION FAIL (A line wasn't connected or a dial tone wasn't detected at
the time of dial calling.)
9. 22 Failed sending during ringing (Conflict between sending and receiving)
Timeout of T0 timer in Phase-A
Timeout of T1 timer in Phase-B
10. 23 Redial All Failed (when all of redialing was NG)
11. 32 V8 negotiation Fail (Not compatible with a sender in V34 receiving)
12. 35 SUB discrepancy in confidential receiving
13. 36 Box full in confidential receiving
14. 37 SEP discrepancy in bulletin board polling sending
15. 38 The box was unavailabl in bulletin board polling sending.
16. 39 The box was unavailabl in confidential receiving.
17. 40 Retry Out (Sent DCS three times in fax sending and no resoponse.)
18. 41 Too Many FTT (Training failure)
19. 43 T2 Time Out (A machine on the other end didn't respond and T2 timeout.)
20. 45 Phase-B Command Rec Error (Failed to receive a control signal at the time of
receiving) (Including SEP discrepancy in bulletin board polling receiving)
21. 46 Phase-B Response Rec Error (Failed to receive a control signal at the time of
sending ) (Including SUB discrepancy in confidential sending)
# Value
(Hex)
Description
22. 47 Phase-B Invalid Command/Response Rx (Received an invalid signal.)
23. 48 A machine on the other end was incapable of receiving.
24. 49 T1 timeout after EOM (T1 timeout after EOM receiving)
25. 4A Invalid CSI error (Dialing numbers didn't match with ID of the machin on the
other end in confirmation sending.)
26. 4B Invalid TSI error (matches number denied acceptance registered as nuisance
fax)
27. 4c FIF:bit49 of a facing machine's DIS was 0 in confidential sending (A facing
machine was incapable of confidential receiving).
28. 4d FIF:bit47 of a facing machine's DIS was 0 in bulletin board polling receiving (A
facing machine was incapable of bulletin board polling sending).
29. 51 Image Data not ready (Decoding or file system error in scanned or received
images)
30. 52 Phase-C Time Out (EOL (not in ECM) or Frame (in ECM) timeout occurred
during data receiving)
31. 60 Retry Out (A machine on the other end made no response in sending Phase-D.
Retry error of post-command.)
32. 65 RNR time out (Time out error of flow control of RR/RNR in sending)
33. 66 RTN/PIN Received, EOR/ERR/DCN (Received RTN/PIN (N-ECM) ERR (ECM))
34. 67 Phase-D Invalid Command/Response Rx (Received an invalid signal.)
35. 69 Phase-D Response Rec Error (Failed to receive a control signal at the time of
sending)
36. 6A EOR error (Received EOR at the time of receiving)
37. 80 MODEM hung-up (Couldn't control a modem)
38. 82 V34 t1 timeout, control channel error (T1 timeout with V34 control channel)
39. 83 V34 t1 timeout, primary channel error (T1 timeout with V34 primary channel)
40. 84 Data not sent until guard timer expire (Timeout at PH-C guard timer)
41. 90 Exceeded the maximum number of digits of dial entry (A maximum of 80 digits
after unfolding a dial symbol)
To Next Page
