CH10/CH20 C. DISASSEMBLY AND ASSEMBLY PROCEDURES
C-2
1-2 Coarse / fine adjustment knob
No. Parts name Screw Grease Adhesive Remarks
•
FINE ADJ.
KNOB
OT1131 Apply adhesive on the attaching part of
fine adj. shaft
±
15
.
‚
SPRING
WASHER
OT2008 With the convex side toward the arm
ƒ
WASHER OT2008
„
FINE SHAFT
MOUNT
…
COARSE ADJ.
KNOB-R
†
TENSION
KNOB
OT2006 Apply grease on M20 screw thread.
‡
SPRING OT2006 Apply grease on the contact points of
spring.
ˆ
TENSION
RING
OT2006 Apply grease on the groove.
‰
ARM AB3X14SA (*1)
±
10
(GEAR ASS’Y) ACU3X14SA
(*2)
Tighten the screw 45° after the screw end
comes in contact with the coarse adj.shaft
±
11
.
±
11
COARSE ADJ.
SHAFT
ER12SA (*3) OT1028 Apply adhesive on the screw thread of
coarse adj. knob
±
13
.
±
12
CAM OT2008 Apply grease on the cam sliding surface
and the fitting surface of coarse adj. shaft
±
11
.
Figure-A (Fine adjustment gear set)
