Olympus DSX510 User Manual

26
*1 DF and MIX are not available *2 Available for BF only *3 At aspect ratio 1:1 diagonal (with factory default value) *4 At aspect ratio 1:1
*1 Cannot be used with the embedded standard LED. *2 Calibration by Olympus or dealer specialists necessary. *3 When the objective lens MPLFLN50XBDP or MPLAPON50X is attached, the stroke is 25 x 25 mm.
DSX510 DSX510i
Main frame
Zoom ratio 13.5X optical zoom (0.26X to 3.5X), 30X with digital zoom
Number of attaching objective lenses up to 2 pieces
Mountable objective lens
DSX dedicated objective lens XLMPLFLN10X, XLMPLFLN40X
UIS2 objective lens
MPLFLN1.25X, MPLFLN2.5X, MPLFLN5XBDP, MPLFLN10XBDP,
MPLFLN20XBDP, MPLFLN50XBDP, LMPLFLN10XBD,
LMPLFLN20X, LMPLFLN50X, MPLAPON50X
Accuracy and repeatability
(X-Y plane)
Accuracy of magnification
±
3%*
2
Repeatability of magnification 3
n-1
=
±
2%
Repeatability (Z axis) Repeatability of height
n-1
≤1µm
-
Illumination
Embedded standard Bright field: LED, Dark field: LED
Optional illumination High intensity LED*
1
/Transmitted LED High intensity LED*
1
Camera
Image sensor
1/1.8 inch, 2.01 megapixels, color CCD (total pixels: 2.10 megapixels)
Total pixels : 1688 (H) x 1248 (V)
Available pixels : 1628 (H) x 1236 (V)
Effective pixels : 1600 (H) x 1200 (V)
Cooling method Peltier cooling
Scan mode Progressive scan
Frame rate 15 fps/27 fps with binning mode
Image size
Normal : 1194 x 1194 (1:1)/1592 x 1194 (4:3)
Fine : 1194 x 1194 (1:1)/1592 x 1194 (4:3)
Super fine : 3594 x 3594 (1:1)/4792 x 3594 (4:3)
Sensitivity ISO 100/200/400/800/1600 equivalent
Focusing unit
Stroke 95 mm 35 mm
Resolution 0.01 m
Maximum sample height
DSX dedicated objective lens 65 mm
-
UIS2 objective lens 95 mm -
Stage
Motorized stage
Model DSX-UFSSU DSX-IFSSU
Stroke 100 x 100 mm 50 x 25 mm*
3
Load capacity 3 kg 1 kg
Manual stage
Model U-SIC4R2 DSX-SFR
Stroke 100 x 105 mm 50 x 25 mm*
3
Load capacity 1 kg 1 kg
LCD monitor
Size 23” with touch panel and Full HD color LCD monitor
Resolution 1920 (H) x 1080 (V)
Weight (Main frame, Motorized stage, LCD monitor, Control box, Controller) Approx. 38.6 kg Approx. 44.1 kg
Input rating 100-120 V/220-240 V, 300 V A, 50/60 Hz
Series Model Parfocal distance NA W.D. (mm) Actual F.O.V. (m)*
3
Total magnification*
4
DSX dedicated objective lens
XLMPLFLN10XDSX*
1
75 mm
0.3 30.0
0 2,772-214 139X-1,803X
XLMPLFLN40XDSX*
1
0.8 04.50 693-54 555X-7,211X
UIS2 objective lens
MPLFLN1.25X*
2
45 mm
0.04
03.50 22,181-1,706 17X-225X
MPLFLN2.5X*
2
0.08 10.70 11,090-853 35X-451X
MPLFLN5XBDP 0.15 12.0
0 3,921-302 69X-901X
MPLFLN10XBDP 0.25
06.50 2,772-214 139X-1,803X
MPLFLN20XBDP 0.4
03.00 1,386-106 277X-3,606X
MPLFLN50XBDP 0.75
01.00 554-42 693X-9,014X
LMPLFLN10XBD 0.25 10.0
0 2,772-214 139X-1,803X
LMPLFLN20XBD 0.4 12.0
0 1,386-106 277X-3,606X
LMPLFLN50XBD 0.5 10.6
0 554-42 693X-9,014X
MPLAPON50X*
1
0.95 00.35 554-42 693X-9,014X
DSX510/510i Specifications
DSX510/510i Series objective lens
