Olympus TG-2 User Manual

41
EN
2 Select the new landmark to be recorded on the
image using FG, and press the A button.
3 Select [OK] using FG, and press the A button.
Rotating images
Rotating images
q
q
[
[
y
y
]
]
Submenu 1 Submenu 2
Edit
y
1 Use HI to select an image.
2 Press the A button to rotate the image.
3 If necessary, repeat Steps 1 and 2 to make
settings for other images, and press the 
button.
Ɣ The new picture orientations will be saved even
after the power is turned off.
Erasing images
Erasing images
q
q
[Erase]
[Erase]
Submenu 2 Application
All Erase
All images in the internal memory
or card will be erased.
Sel. Image
Images are individually selected
and erased.
Erase Deletes the image displayed.
Erase Group
All images in the group are
erased.
Ɣ When erasing pictures in the internal memory, do
not insert the card into the camera.
Ɣ Protected images cannot be erased.
To individually select and erase images
To individually select and erase images
[Sel. Image]
[Sel. Image]
1 Use FG to select [Sel. Image], and press the
A button.
2 Use FGHI to select the image to be erased,
and press the A button to add a R mark to the
image.
Ɣ Press the T button to the single frame display.
Sel. Image (1)
Erase/Cancel
OK
MENU
4/304/30
R mark

Olympus TG-2 Specifications

General

Sensor Type	CMOS
Sensor Size	1/2.3 inch
Effective Pixels	12 MP
Display Size	3.0 inch
Battery	LI-90B Lithium-Ion Battery
Type	Compact
Digital Zoom	4x
Focal Length	4.5 - 18.0 mm
Focal Length (Equivalent)	25 - 100 mm
Image Processor	TruePic VI
LCD Screen Resolution	610, 000 dots
Video Recording	Yes
Battery Type	Lithium-Ion
Dimensions	111.5 x 66.5 x 29.1 mm
Lens	4x optical zoom
Aperture	f/2.0 - f/4.9
ISO Sensitivity	ISO 100-6400
Waterproof	15 m / 50 ft
Shockproof	2.1 m / 7 ft
Freezeproof	-10°C / 14°F
Weight	230 g / 8.1 oz
Video Resolution	1920 x 1080 (Full HD)
Shutter Speed	1/2000 to 4 sec
Crushproof	100 kgf / 220 lbf
