Omron E5CZ Manual

Digital Temperature Controllers E5CZ 13
■ Accessories (Order Separately)
Current Transformers (CTs)
Specifications
■ Ratings
■ Input Ranges
Platinum Resistance Thermometer Input
Thermocouple Input
Shaded setting indicates the default setting.
ES1B Infrared Temperature Sensor
Model E54-CT1 E54-CT3
Hole diameter 5.8 dia. 12.0 dia.
Power supply voltage 100 to 240 VAC, 50/60 Hz 24 VAC/VDC, 50/60 Hz
Operating voltage range 85% to 110% of rated supply voltage
Power consumption 7 VA 5 VA, 3 W
Sensor input Thermocouple: K, J, T, E, L, U, N, R, S, B
Platinum resistance thermometer: Pt100, JPt100
Infrared temperature sensor: 10 to 70
°C, 60 to 120°C, 115 to 165°C, 140 to 260°C
Voltage input: 0 to 50 mV
Control output Relay output SPST-NO, 250 VAC, 3 A (resistive load), electrical life: 100,000 operations
Voltage output 12 VDC
+15%
/
−20%
(PNP), max. load current: 21 mA, with short-circuit protection circuit
Current output 4 to 20 mA DC, load: 600
Ω max., resolution: approx. 2,600
Alarm output SPST-NO, 250 VAC, 1 A (resistive load), electrical life: 100,000 operations
Event input Contact input ON: 1 k
Ω max., OFF: 100 kΩ min.
Non-contact input ON: Residual voltage: 1.5 V max., OFF: Leakage current: 0.1 mA max.
Outflow current: Approx. 7 mA per point
Control method 2-PID control or ON/OFF control
Setting method Digital setting using front panel keys
Indication method 7-segment digital display and single-lighting indicators
Character height: PV: 10.0 mm; SV: 6.5 mm
Other functions According to Controller model
Ambient operating temperature
−10 to 55°C (with no condensation or icing)
Ambient operating humidity 25% to 85%
Storage temperature
−25 to 65°C (with no condensation or icing)
Input type Pt100 JPt100
Temperature
range
−200 to
850°C
−199.9 to
500.0°C
0.0 to
100.0°C
−199.9 to
500.0°C
0.0 to
100.0°C
Setting number 01234
Input type K J T E L U N R S B
Temperature
range
−200 to
1300°C
−20 to
500°C
−100 to
850°C
−20.0 to
400.0°C
−200 to
400°C
−199.9 to
400.0°C
0 to
600°C
−100 to
850°C
−200 to
400°C
−199.9 to
400.0°C
−200 to
1300°C
0 to
1700°C
0 to
1700°C
100 to
1800°C
Setting number
5 6 7 8 9 22 10111223 13141516
Input type 10 to 70°C 60 to 120°C 115 to 165°C 140 to 260°C
Temperature
range
0 to 90°C 0 to 120°C 0 to 165°C 0 to 260°C
Setting number 17 18 19 20
