37
Recommended Network Devices Section 2-2
2-2 Recommended Network Devices
The following table shows the devices recommended for use with the Ether-
Net/IP.
Note (1) Always use a switching hub when using tag data links in the network.
(2) If a repeater hub is used for EtherNet/IP tag data links (cyclic communi-
cations), the network’s communications load will increase, data collisions
will occur frequently, and stable communications will be impossible.
2-2-1 Network Devices Manufactured by OMRON
The following network devices are manufactured by OMRON for EtherNet/IP
networks.
Part Maker Model number Inquires
Switching
Hub
Cisco Systems, Inc. Consult the manufacturer. Cisco Systems, Inc. Main Corpo-
rate HQ
Contec USA, Inc. Consult the manufacturer. CONTEC USA Inc.
Phoenix Contact Consult the manufacturer. Phoenix Contact USA Customer
Service
Twisted-pair
cable
100BASE-TX
Fujikura F-LINK-E 0.5mm × 4P Fujikura America, Inc.
EtherNet/IP compliant cable ---
Connectors
(Modular
plug)
STP Plug
Panduit Corporation MPS588 Panduit Corporation US Headquar-
ters
Boots Tsuko Company MK boot (IV) LB Tsuko Company Japan Headquar-
ters
Name Model Function Number of
ports
Error detection
output
Switching Hub W4S1-03B Packet priority control (QoS):
EtherNet/IP control data priority
Failure detection: Broadcast
storm, LSI error detection, 10/
100Base-TX, Auto-Negotiation
3None
W4S1-05B 5 None
W4S1-05C 5 Provided.
W4S1-10B 10 None
W4S1-10C 10 Provided.
