4. Creating Data Set for Robot Vision
This chapter describes procedures to create robot programs (sample program) for the
robot controller and data (environment data) for the Vision Sensor to construct robot
vision applications.
Please follow the flow below for the settings.
4.1
Creating data set
Select the robot manufacturer to
connect, application type to construct,
and camera mounting method to
output a data set for the robot vision.
4.1. Creating Data Set
Follow the procedures below to create a data set for the robot vision.
1
Launch the output tool for the
data set for the robot vision.
2
Select a robot manufacturer to
connect from the combo box.
3
Select an application to
construct by clicking the radio
button at the left of the
application name. Select a
camera mounting method from
the combo box at the right.
