No. 13S054-10

STC-HD203DV / STC-HD203DV-CS / STC-HD203SDI / STC-HD203SDI-CS

Product Specifications and Users Guide

12/78

4.5 External Control Specification

Circuit Diagram of SW Board to connect 3.5φStereo Pin Jack

Tip

GND

SW-A SW-B SW-C SW-D SW-E SW-F

1 2

1.8K

3.3K

4.7K

10K

27K
