Omron STC-HD203 Series User Manual

No. 13S054-10
STC-HD203DV / STC-HD203DV-CS / STC-HD203SDI / STC-HD203SDI-CS
Product Specifications and Users Guide
44/78
Push button function list
Value Function Function Description
0x00 Disabled Disable Push button control
0x01 Display Menu Display Menu on the screen
0x02 Push Lock WB [Save] Execute Push Lock White Balance. And save the setting as AWB HOLD on the
EEPROM
0x03 WB mode(AWB) [Save]
Set White Balance Mode：Auto, and save the setting on EEPROM
0x04 Change H Inversion Horizontal flip the image
0x05 Change V Inversion Vertical flip the image
0x06 Change HV Inversion Horizontal-Vertical flip the image
0x07 Change H Inversion [Save] Save the setting after H flip the image
0x08 Change V Inversion [Save] Save the setting after V flip the image
0x09 Change HV Inversion [Save] Save the setting after H-V flip the image
0x0A Change display marker Set the marker display enable or disable
0x0B Change display line Set the line display enable or disable
0x0C Change display shadow Set the shadow mask display enable or disable
0x0D Change display marker [Save] Set the marker display enable or disable, and save the setting on EEPROM
0x0E Change display line [Save] Set the line display enable or disable, and save the setting on EEPROM
0x0F Change display shadow [Save] Set the shadow mask display enable or disable, and save the setting on
EEPROM
0x10 H Line Maker1 position (+) Horizontal Line Marker1 shift to the bottom.
0x11 H Line Maker1 position (-) Horizontal Line Marker1 shift to the top.
0x12 V Line Maker1 position (+) Vertical Line Marker1 shift to the left.
0x13 V Line Maker1 position (-) Vertical Line Marker1 shift to the right.
0x14 H Line Maker2 position (+) Horizontal Line Marker2 shift to the bottom.
0x15 H Line Maker2 position (-) Horizontal Line Marker2 shift to the top.
0x16 V Line Maker2 position (+) Vertical Line Marker2 shift to the left.
0x17 V Line Maker2 position (-) Vertical Line Marker2 shift to the right.
0x18 Shadow mask Top (+) Shadow mask on top shift to the bottom.
0x19 Shadow mask Top (-) Shadow mask on top shift to the top.
0x1A Shadow mask Bottom (+) Shadow mask on bottom shift to the bottom.
0x1B Shadow mask Bottom (-) Shadow mask on bottom shift to the top.
0x1C Shadow mask Left (+) Shadow mask on left shift to the right.
0x1D Shadow mask Left (-) Shadow mask on left shift to the left.
0x1E Shadow mask Right (+) Shadow mask on right shift to the right.
0x1F Shadow mask Right (-) Shadow mask on right shift to the left.
0x20 Change display circle marker Set the circle marker display enable or disable
0x21 Change display circle marker [Save} Set the circle marker display enable or disable, and save the setting on
EEPROM
0x22 H Circle Maker position (+) The center of Circle Maker shift to the right.
0x23 H Circle Maker position (-) The center of Circle Maker shift to the left.
0x24 V Circle Maker position (+) The center of Circle Maker shift to the bottom.
0x25 V Circle Maker position (-) The center of Circle Maker shift to the top.
0x26 Change Still image Set the still image display enable or disable
