No. 13S054-10
STC-HD203DV / STC-HD203DV-CS / STC-HD203SDI / STC-HD203SDI-CS
Product Specifications and Users Guide
62/78
Menu on screen with External Switch
Page 1
1) AE MODE
Selects the exposure and the gain operation mode from below three modes. (Default: NORMAL).
a) NORMAL
The auto exposure and the auto gain operation.
The auto exposure operation mode when “OFF” is selecting at “PRI SHUTTER”
The longest exposure time is “1 / frame rate” time for the auto exposure operation.
If “PRI SHUTTER” selects other than “OFF”, the camera operates with the selected exposure time.
The auto gain operation mode when “OFF” is selecting at “PRI GAIN”.
If “PRI GAIN” selects other than “OFF”, the camera operates with the selected gain.
Sets the target brightness level at “LUMINANCE” when “PRI SHUTTER” or “PRI GAIN” is OFF.
b) LONG
The auto exposure and the auto gain operation with the long exposure control.
The auto exposure operation mode when “OFF” is selecting at “PRI SHUTTER”.
The exposure time becomes more than “1 / frame rate” time, which is the long exposure control
depending on the target brightness. The frame rate becomes slower when the camera operates with
the long exposure control.
The auto gain operation mode when “OFF” is selecting at “PRI GAIN”.
If “PRI GAIN” selects other than “OFF”, the camera operates with the selected gain.
Sets the target brightness level at “LUMINANCE” when “PRI SHUTTER” or “PRI GAIN” is OFF.
c) USER MODE
The manual exposure and the manual gain operation.
Sets the manual exposure time at “USER SHUTTER” and the manual gain at “USER GAIN”.
PAGE 1 2 3 4 5 6
AE MODE NORMAL
LUMINANCE 00000
PRI GAIN 27.09 dB
PRI SHUTTER 0000 1/1000s
USER GAIN 000 46.2dB
USER SHUTTER 0000 1/1000s
GAMMA 0.45
To Next Page
