No. 13S054-10
STC-HD203DV / STC-HD203DV-CS / STC-HD203SDI / STC-HD203SDI-CS
Product Specifications and Users Guide
37/78
Slave address for the ICs (8 bits) list
IC Slave Address 詳細
DSP 80 DSP data
EEPROM 60 The Virtual EEPROM zone for the currently selected DSP preset
mode of Preset0 to Preset7
EEPROM 90 The EEPROM zone for the Preset0 DSP data
EEPROM 91 The EEPROM zone for the Preset1 DSP data
EEPROM 92 The EEPROM zone for the Preset2 DSP data
EEPROM 93 The EEPROM zone for the Preset3 DSP data
EEPROM 94 The EEPROM zone for the Preset4 DSP data
EEPROM 95 The EEPROM zone for the Preset5 DSP data
EEPROM 96 The EEPROM zone for the Preset6 DSP data
EEPROM 97 The EEPROM zone for the Preset7 DSP data
uCOM 20 The uCOM data
EEPROM 40 The EEPROM zone for uCOM Data
Note: There is maximum number of writing to EEPROM of 1,000,000 times.
Error code list
If an error occurs, the camera sends an error code with the following format:
The Command number of the Error Message is FF (HEX). The Data length is 0002.
Error Receive data
Check sum does NOT match the data being transmitted 02, FF, 00, 02, 03, 00, 04, 03
The command being transmitted does NOT exist or is invalid 02, FF, 00, 02, 04, 00, 05, 03
Unprocessed data remains in the receiving buffer 02, FF, 00, 02, 05, 00, 06, 03
Time out 02, FF, 00, 02, 06, 00, 07, 03
Over run error 02, FF, 00, 02, 08, 00, 09, 03
Framing error 02, FF, 00, 02, 09, 00, 0A, 03
Data length error (too long) 02, FF, 00, 02, 0B, 00, 0C, 03
I2C communication error 02, FF, 00, 02, 10, 00, 11, 03
Note.1: The camera disregards the data, which is not start with SOF.
Note.2: The time out error is occurred when does not receive the next data 3 seconds after receive the data.
