Omron STC-HD203 Series User Manual

No. 13S054-10
STC-HD203DV / STC-HD203DV-CS / STC-HD203SDI / STC-HD203SDI-CS
Product Specifications and Users Guide
9/78
STC-HD203SDI / STC-HD203SDI-CS
Default: Bold
(*1) Longest exposure time is depending on video output mode
Model Number STC-HD203SDI STC-HD203SDI-CS
Image Sensor 1/2.8" 2.3M Progressive Color CMOS (SONY: IMX136)
Shutter Type Rolling Shutter
HD Active Picture Elements 1,920 (H) x 1,080 (V)
Cell Size 2.8 (H) x 2.8 (V) µm
Sync. System Internal
Minimum Scene Illumination 0.6 Lux (AGC ON) @F1.2
Video Output 3G-SDI (Physical layer: SMPTE 424M, Data Mapping: SMPTE 425M Level-A Compliant),
4:2:2 YCbCr 10bit 1080P60 / 1080P59.94 / 1080P50
HD-SDI (SMPTE292M Compliant) 4:2:2 YCbCr 10bit 1080P30 / 1080P29.97 / 1080P25
720P60 / 720P59.94 / 720P50
(Default: 1080P60)
Camera functions
ALC Can be configured via the UART communication with auto electronic shutter and AGC
Shutter Speed Adjustable shutter speed via the UART communication (AEE) (Default: Auto)
Extended Extend shutter frame unit (Up to 2.55 seconds)
High Speed From 1/10,000 seconds (*1)
Gain AGC or Fixed gain selectable via the UART communication (Default: AGC)
0 to 45 dB
Gamma Selectable gamma through 5 preset (one preset is manual / 0.45 / 0.6 / 0.8 / 1)
Selectable gamma via the UART communication (Default: manual)
White Balance Auto white balance / manual white balance / push to set white balance
Selectable white balance via the UART (Default: Auto white balance)
WDR Wide Dynamic Range OFF/ON (Default: OFF)
WDR enable via the UART communication
Mirror Image Normal image / horizontal flip / vertical flip / horizontal vertical flip (180 deg. rotation)
(Default: Normal image)
Picture Modes 8 user preset mode, Normal picture mode or pseudo color mode can be selectable
Selectable picture mode via the UART communication (Default: Preset 0)
Line Generator Both horizontal and vertical with all available colors (Line number: 2)
Adjustable thickness via the UART communication (Default: Disable)
Shadow Mask
Generator
Both horizontal and vertical with shading level adjustment via the UART communication
(Default: Disable)
Still Image Selectable Live image or freeze image via the UART communication
Communication +3.3V UART communication via 3.5Φ Stereo Jack
(Baud rate: 38,400bps / 19,200bps / 9,600bps)
Character Generator Built-in character generation function via the UART communication
Defective Pixel
Collection
Support
Power Input Voltage +9 to +15 Vdc (Typical: +12 Vdc)
Consumption 4.4 W (Typical)
