ZFX-C Serial Communication Command Reference
Measurement Control/Measurement Value Acquisition
Commands
Acquiring the Measurement Result of the Measurement Item < MEASDATA command >
This command acquires the measurement result of the measurement item.
< Command format >
< Response format >
< Explanation of parameters >
Measurement item No. Specifies the measurement item No. (0 to 127 (ZFX-C20/C25/C10H/C15H), 0 to 31 (ZFX-
C10/C15))
Data No. Specifies the data No. (0 to 127)
For details, see "Parameter List (p.39)."
Measurement value The acquired measurement value is returned in ASCII code.
The measurement value is not dependent on the format (ASCII/binary) specified in the
output conditions.
• Minus sign: -, plus sign: none
• The size of the integer section is variable.
• The decimal point is indicated by a period ".".
• The maximum number of digits past the decimal point is three.
MEA S
C
R
MD
C
R
D A T A
or
Data No.
(max. 3 digits)
Data No.
(max. 3 digits)
Measurement
item No.
(max. 3 digits)
Measurement
item No.
(max. 3 digits)
O K
C
R
E R
C
R
C
R
When processing ends successfully
When processing fails
Measurement value
