Omron ZFX-C Command Reference

About Communication Commands
ZFX-C Serial Communication Command Reference
25
Backup/Restore Commands
Uploading Bank Group Data < BGRLOAD command >
Uploading bank group data to the Controller from an external device
This command uploads the bank group data to the Controller by XMODEM protocol. The bank group data is
loaded to the specified bank group No.
< Command format >
< File transfer >
The bank group data is transferred by XMODEM (-CRC or SUM) after READY is received. XMODEM (-1K) is
not supported.
< Response format >
< Explanation of parameters >
Uploading bank group data to the Controller from an SD card
This command uploads bank group data to the Controller from an SD card.
< Command format >
< Response format >
< Explanation of parameters >
Bank group No. Specifies the bank group No. to upload. (0 to 31)
Bank group No. Specifies the bank group No. to upload. (0 to 31)
File name Specifies the file name within eight alphanumeric characters. (An extension is not required.)
B GR L
C
R
G L
C
R
O A D 00
Bank group No.
(max. 2 digits)
or
Bank group No.
(max. 2 digits)
OK
C
R
ER
C
R
R EAD
C
R
Y
When processing ends successfully
When processing fails
B GRL
C
R
GL
C
R
O A D11
or
File name File name
Bank group No.
(max. 2 digits)
Bank group No.
(max. 2 digits)
OK
C
R
ER
C
R
When processing ends successfully
When processing fails
