Omron ZFX-C Command Reference

About Communication Commands
ZFX-C Serial Communication Command Reference
39
Parameter List
MEASDATA Command
Shape inspection parameters
Pattern search
Graphic search (available only on ZFX-C20/C25/C10H/C15H)
Data No. Parameter Output Range
0 Judgment result 0: OK
-1: NG
-2: not measured
1 Correlation 0 to 100
2 Measurement position X -9999.999 to 9999.999
3 Measurement position Y -9999.999 to 9999.999
4 Measurement angle -180 to 180
5 Search number 0 to 99
6 Reference position X -9999.999 to 9999.999
7 Reference position Y -9999.999 to 9999.999
8 Reference angle -180 to 180
9 Position difference X -9999.999 to 9999.999
10 Position difference Y -9999.999 to 9999.999
11 Angle difference -180 to 180
Data No. Parameter Output Range
0 Judgment result 0: OK
-1: NG
-2: not measured
1 Correlation 0 to 100
2 Measurement position X -9999.999 to 9999.999
3 Measurement position Y -9999.999 to 9999.999
4 Measurement angle -180 to 180
5 Search number 0 to 99
6 Reference position X -9999.999 to 9999.999
7 Reference position Y -9999.999 to 9999.999
8 Reference angle -180 to 180
9 Position difference X -9999.999 to 9999.999
10 Position difference Y -9999.999 to 9999.999
11 Angle difference -180 to 180
