Advanced Settings
24
1.Input/Output Assign
Monitor Out
The video input signals input to the unit will be converted when they are output from the
HDMI OUT jack to the TV so that their resolution can match that of the TV used.
Setting Item Default Value Setting Details
Monitor Out MAIN Select the HDMI jack to be connected with TV.
"MAIN": When connecting the TV to the HDMI OUT
MAIN jack
"SUB": When connecting the TV to the HDMI OUT
SUB jack
"MAIN+SUB": When connecting to both the MAIN
and SUB jacks
r
Video signals input to the COMPOSIT VIDEO
input jack or the COMPONENT VIDEO input jacks
will be upconverted to HDMI signals and then
output from the HDMI OUT jack.
r
Different "Resolution" values can be set for “MAIN”
and “SUB”.
r
The HDMI jack of this unit is compliant with
HDCP2.2 (HDMI OUT MAIN and HDMI IN3 jacks
only).
Out
Use
connected to the HDMI OUT ZONE2 jack.
"Use": Enable this function
"Not Use": Disable this function
Setting Item Default Value Setting Details
Resolution Through Specify the output resolution of the HDMI OUT jacks.
The image resolution of the unit will be converted so
that it can match the resolution supported by the TV
used.
"Through": The output resolution will be the same as
that of the input signals.
"Auto": The resolution will automatically be converted
according to the resolution supported by the TV.
"480p (480p/576p)", "720p", "1680×720p", "1080i",
"1080p", "2560×1080p": Select the desired
resolution.
"4K": About four times as high resolution as 1080p
(3840×2160 or 4096×2160 pixels depending on the
resolution supported by the connected TV)
"Source": The output resolution will be the one set for
"Resolution" which is shown in the section "4. Source
Setup" - "Picture Adjust" - "Resolution".
r
If "1080p" is selected, 1080p/24 input signals will
be output with an unchanged resolution.
r
If the selected resolution is not supported by the
monitor, the video is output in the same resolution
as the input signal.
r
If "4K" is selected, video signals may not be
output to some types of TV. For details, see
"Supported Video Resolution of HDMI OUT MAIN/
SUB Jacks" in "Troubleshooting".
r
If "Monitor Out" is set to "MAIN+SUB", only
"Through" or "Auto" can be set.
r
You can check the video on the TV while making
this setting. Select the value with the cursors
and press ENTER. Press RETURN if no video
is displayed. (except when "NET", "USB" or
"BLUETOOTH" is selected)
To Next Page
