Onkyo TX-NR696-S User Manual

96
Front Panel≫ Rear Panel≫ Remote≫
Contents
≫
Connections
≫
Playback
≫
Setup
≫
Input Formats and Selectable Listening Modes
You can select a variety of listening modes
according to the audio format of the signal to be
input.
• List of listening modes selectable with the
MOVIE/TV button ( p96)
• List of listening modes selectable with the MUSIC
button ( p100)
• List of listening modes selectable with the GAME
button ( p105)
• Selectable listening modes when headphones
are connected are Pure Audio, Mono, Direct, and
Stereo only.
 MOVIE/TV button
Input Format Listening Mode
Analog Direct
Mono
DSur
DTS Neural:X
DTS Virtual:X
*1 *2
THX Cinema
*3
TV Logic
*4
AllCh Stereo
*5
Full Mono
*5
T-D
*1
*1
Cannot be selected when "Speaker Virtualizer" is set to "O󰀨".
*2
Cannot be selected when height speakers are installed.
*3
Surround speakers need to be installed.
*4
Surround speakers or height speakers need to be installed.
*5
A center speaker, surround speakers, or height speakers need to be
installed.
Input Format Listening Mode
PCM
Music les (except DSD)
Direct
Mono
DSur
DTS Neural:X
*1
DTS Virtual:X
*2 *3
THX Cinema
*4
TV Logic
*5
AllCh Stereo
*6
Full Mono
*6
T-D
*2
*1
Cannot be selected when the input format is monaural.
*2
Cannot be selected when "Speaker Virtualizer" is set to "O󰀨".
*3
Cannot be selected when height speakers are installed.
*4
Surround speakers need to be installed.
*5
Surround speakers or height speakers need to be installed.
*6
A center speaker, surround speakers, or height speakers need to be
installed.
❏ Speaker Layouts and
Selectable Listening Modes
( p87)

Onkyo TX-NR696-S Specifications

General

THX-certified	THX Select
3D	Yes
Supported graphics resolutions	3840 x 2160
HDCP version	2.2
Apple docking	-
Product color	Silver
Audio decoders	DTS Virtual:X, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Volume control	Rotary
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Internet radio services supported	Deezer, Spotify, Tidal, TuneIn
Receiver type	Surround
Output impedance	470 Ω
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	106 dB
Total Harmonic Distortion (THD)	0.08 %
Dynamic power per channel (3 Ohm)	240 W
Dynamic power per channel (4 Ohm)	210 W
Dynamic power per channel (8 Ohm)	120 W
Power output per channel (1KHz@6 Ohm)	175 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio formats supported	AIFF, ALAC, DSD, FLAC, WAV
HDMI in	7
Digital audio optical in	1
Headphone connectivity	6.3 mm
Number of HDMI outputs	2
Phono inputs (RCA)	4
Connectivity technology	Wired & Wireless
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.15 W
Power consumption (typical)	570 W
Package depth	468 mm
Package width	534 mm
Package height	265 mm
Package weight	12500 g
Optical drive included	No

Weight and Dimensions

Depth	379.5 mm
Width	435 mm
Height	173.5 mm
Weight	10000 g
