Onkyo TX-RZ1100 User Manual

2
> Specifications > Settings > Listening Modes > Playback Function > Basic Manual
Troubleshooting | Appendix
Main features
This unit is connected between your TV and your AV
components. To play, select the source with the input
selector. This unit has a 9 ch amplifier plus pre out jack for
powered subwoofer.
•
Conforms to the THX Select2 Plus specification:
THX is a series of specifications for the accurate
reproduction of movies propounded by the film director
George Lucas. This unit is equipped with a variety of
THX technology to faithfully reproduce according to
the sound design envisaged by the movie producer,
including surround modes that take account of factors
such as the size and number of speakers, and the
differences in environments between home theaters and
movie theaters.
•
Supports playback in Dolby Atmos format and has
Dolby Surround listening mode
•
Supports playback in DTS:X format and has DTS
Neural:X listening mode
•
The HDMI jack supports 4K video input and output.
Jacks IN1 to 5 and OUT MAIN/SUB support HDCP2.2
•
HDMI CEC functionality: Control features such as
linking input switching with the input selector and
players conforming to the CEC standard, switching
audio output and volume using the remote controller of
a CEC-compliant TV, and automatically switching this
unit to standby when the TV is turned off
•
HDMI Standby Through: Video and audio signals from
AV components can be transmitted to the TV even if this
unit is in standby
•
ARC: Connection with an ARC-compatible TV is
complete with one HDMI cable
•
Easy Initial Setup using onscreen guidance and On-
Screen Display (OSD) showing operations on the TV
•
Internet radio and AirPlay via wired LAN or Wi-Fi
(wireless LAN) and network features such as Music
Server that enables PC music file playback, USB
playback, plus other playback features such as AM/FM
radio and BLUETOOTH
R
play
•
Playback formats supported by Music Server and USB
include WAV, FLAC and DSD high-res source
•
Multi-zone Connection which allows you to play in the
main room and listen in a separate room (ZONE 2/
ZONE 3)
•
Equipped with RS232 port, IR IN jack, and 12V
TRIGGER OUT jack

Onkyo TX-RZ1100 Specifications

General

Impedance	16 Ω
Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	9.2 channels
Signal-to-Noise Ratio (SNR)	108 dB
Total Harmonic Distortion (THD)	0.04 %
Dynamic power per channel (3 Ohm)	320 W
Dynamic power per channel (4 Ohm)	270 W
Dynamic power per channel (8 Ohm)	160 W
AM band range	530 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
AC input voltage	220-230 V
AC input frequency	50 - 60 Hz
Package weight	22500 g
Manual	Yes
Product color	Silver
Audio decoders	DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby TrueHD
HDMI in	8
Audio (L/R) in	7
USB ports quantity	1
Digital audio optical in	3
Component video (YPbPr/YCbCr) in	2

Weight and Dimensions

Depth	453 mm
Width	435 mm
Height	201 mm
Weight	19700 g
